Yellow plastic pendant control station with two black and white push buttons, rectangular enclosure 4.33 by 2.76 by 3.27 inches

SQUARE D

SQUARE D XACA201 2NO Yellow Pendant Control Station 10A 600V IP65

SKU CH-QQVX-TCTMG

Two-momentary-button pendant station with 2NO contacts rated 10 A at 600 V, IP65 and NEMA 4/4X/5 in a yellow plastic enclosure

  • Engine BrandSQUARE D
  • Two momentary push buttons for direct up/down control
  • Yellow IP65 plastic enclosure resists dust and water jets
  • Mechanical interlock prevents simultaneous activation of both contacts
  • Rated 10 A at 600 V AC/DC for industrial circuits
  • CSA and UL listed for compliant installations

Yellow pendant control station for industrial use

The SQUARE D XACA201 is a yellow pendant control station designed for industrial environments. It provides two momentary push-button operators with a mechanical interlock to prevent simultaneous activation. The enclosure carries NEMA 4, 4X and 5 ratings plus IP65 ingress protection for dust and water resistance.

Contact rating and wiring limit

Each contact is rated at 10A at 600V AC/DC with an A600/Q600 NEMA designation. The station includes a 1/2 in.-14 NPT hub for conduit entry, which defines the maximum conduit size that can be connected directly to the enclosure.

Two normally-open contacts with interlock

The unit supplies two normally-open contacts operated by black and white push buttons labelled Up and Down. The mechanical interlock ensures only one contact can close at a time, making it suitable for applications that require mutually exclusive start/stop or up/down control.

商品特色

  • Two momentary push buttons for direct up/down control
  • Yellow IP65 plastic enclosure resists dust and water jets
  • Mechanical interlock prevents simultaneous activation of both contacts
  • Rated 10 A at 600 V AC/DC for industrial circuits
  • CSA and UL listed for compliant installations

商品規格

Engine BrandSQUARE D

商品問答

Which version of the XACA201 pendant control station should I choose for a two-function application?

The XACA201 provides two momentary push-button operators with a 2NO contact form, giving independent up and down control in a single yellow enclosure rated IP65 and NEMA 4/4X/5.

What does the 10A 600V rating mean when the station is wired into my control circuit?

Each contact is rated for 10 amperes at 600 volts AC or DC, matching the A600/Q600 NEMA designation for heavy-duty pilot-duty switching.

How does the 1/2 inch NPT hub affect the cable entry and sealing?

The 1/2 in.-14 NPT hub accepts standard conduit fittings and, together with the IP65 enclosure, maintains a watertight and dust-tight seal at the cable entry point.
