Green Mini PCIe card with single RJ45 port and LED light

Vszerda

Vszerda Mini PCIe Gigabit Ethernet Network Card

SKU CH-72AM-V6B2Y

Adds a single gigabit RJ45 port via Mini PCIe using an Intel I210AT controller with low-profile and full-height brackets

  • StandardsEthernet
  • Speed1000 megabits_per_second
  • ConnectorsEthernet
  • Interfaceethernet
  • BUSethernet
  • Weight0.01 ounces
  • Gigabit wired networking for servers and workstations
  • Intel I210AT controller delivers reliable throughput
  • Broad OS support including Windows Server and Linux
  • Advanced features such as PXE, DPDK, WOL and jumbo frames
  • Low-profile and full-height brackets fit standard or slim chassis

Mini PCIe Gigabit Ethernet card

This Vszerda network card adds a single RJ45 port to any system with a free Mini PCIe slot. It is aimed at server administrators and embedded builders who need a reliable wired link without using an M.2 connector. The board ships with both low-profile and full-height brackets for standard or slim chassis.

Intel I210AT controller

The card is built around the Intel I210AT chip, which determines compatibility and feature support. It handles 10, 100 and 1000 megabits per second over Cat5e cable up to 100 metres and enables PXE, DPDK, WOL, iSCSI, jumbo frames and Windows 10 teaming. FCoE is not supported.

Thermals and power

The controller runs cool enough for continuous server duty without active cooling. Passive operation keeps noise at zero in normal use. Power draw is minimal and satisfied directly from the Mini PCIe slot.

商品特色

  • Gigabit wired networking for servers and workstations
  • Intel I210AT controller delivers reliable throughput
  • Broad OS support including Windows Server and Linux
  • Advanced features such as PXE, DPDK, WOL and jumbo frames
  • Low-profile and full-height brackets fit standard or slim chassis

商品規格

BrandH!Fiber.com
StandardsEthernet
Speed1000 megabits_per_second
ConnectorsEthernet
Interfaceethernet
BUSethernet
Weight0.01 ounces

商品問答

What does the 1000 megabits per second rating mean once the card is installed in a server?

It provides a single gigabit Ethernet link over Cat5e cable up to 100 metres, using the Intel I210AT controller for stable throughput.

Which bus interface does the card use and what does it limit?

The card uses a Mini PCIe interface, not M.2, and the bus caps the port at 1000 megabits per second.

What brackets are included so the card fits in standard or slim chassis?

Both a low-profile bracket and a full-height bracket are supplied, covering standard and slim servers.
