Silver 1U rack server front with four 3.5-inch drive trays

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2× Xeon E5-2660 v4 2.0 GHz 14-core 64 GB DDR4

SKU CH-S5KW-H16E6

A 1U rack server with dual 14-core Xeon processors at 2.0 GHz, 64 GB DDR4 ECC memory, an LSI MegaRAID 9361-8i controller, four 3.5-inch hot-plug drive bays.

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual 14-core Xeon E5-2660 v4 processors at 2.0 GHz base and 3.2 GHz turbo
  • 64 GB DDR4 2400 MHz registered ECC memory across four 16 GB modules
  • LSI MegaRAID 9361-8i with 1 GB cache and battery backs RAID 0/1/5/6/10/50/60
  • Four 3.5" hot-swap SATA/SAS drive bays with included trays
  • Quad-port Intel X540 10GBase-T plus dedicated IPMI 2.0 management LAN
  • Redundant 750 W platinum power supplies in 1U rack form factor

Dual Xeon E5-2660 v4 1U Server

The Supermicro SYS-6018U-TR4T+ is a 1U rackmount server equipped with two Intel Xeon E5-2660 v4 processors. Each CPU runs at 2.0 GHz with 14 cores and reaches 3.2 GHz turbo frequency. The system includes 64 GB of DDR4 2400 MHz registered ECC memory across four modules. It is built for virtualization, high-performance computing and cloud workloads that demand dense parallel processing.

LSI MegaRAID 9361-8i Controller Limits

Storage is managed by an LSI MegaRAID 9361-8i controller with eight ports of SAS 12 Gb/s connectivity and 1 GB cache backed by a battery. The controller supports RAID 0, 1, 5, 6, 10, 50 and 60 levels. Only four 3.5-inch hot-plug drive bays are provided, so the eight-port controller cannot be fully populated with internal drives. No solid-state drives are installed and the front bezel plus rack rails are not included.

Quad 10GBase-T Ports Decide Fit

Network connectivity comes from a Supermicro AOC-UR-i4XT add-on card based on the Intel X540 controller, delivering four RJ45 10GBase-T ports. A dedicated RJ45 IPMI 2.0 port enables remote KVM-over-LAN and virtual media management. Redundant 750 W platinum power supplies handle the dual-CPU load. Buyers needing more than four drive bays or fibre-channel networking will need a different chassis.

Puntos fuertes

  • Dual 14-core Xeon E5-2660 v4 processors at 2.0 GHz base and 3.2 GHz turbo
  • 64 GB DDR4 2400 MHz registered ECC memory across four 16 GB modules
  • LSI MegaRAID 9361-8i with 1 GB cache and battery backs RAID 0/1/5/6/10/50/60
  • Four 3.5" hot-swap SATA/SAS drive bays with included trays
  • Quad-port Intel X540 10GBase-T plus dedicated IPMI 2.0 management LAN
  • Redundant 750 W platinum power supplies in 1U rack form factor

Especificaciones

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2660 V4
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Preguntas sobre este artículo

Should I pick the 1U 4-bay 3.5" model or a 2.5" variant for my rack?

This unit is a 1U chassis with four 3.5-inch hot-plug bays and no drives installed; choose it when you need 3.5-inch SAS or SATA capacity in a single rack unit.

What does the 2.0 GHz base and 3.2 GHz turbo mean for real workloads?

Each Xeon E5-2660 v4 runs at 2.0 GHz base and can reach 3.2 GHz turbo across its 14 cores, so sustained multi-threaded tasks sit near the base clock while bursty jobs hit the higher frequency.

How does the X540 10GBase-T adapter limit network speed in practice?

The quad-port X540 controller caps each RJ45 link at 10 Gb/s over twisted-pair copper, so aggregate throughput tops out at 40 Gb/s when all four ports are active.
