Supermicro 4U rack server with 36 front drive bays, dual Xeon CPUs, 64GB DDR4, redundant PSUs

Supermicro

Supermicro SYS-6048R-E1CR36N 36 Bay 3.5" 4U Server 2x Xeon E5-2667 v4 3.2GHz 64GB DDR4 9361-8i

SKU CH-P2KE-N3G3M

A 4U server with 36 hot-swap 3.5" drive bays, dual Xeon E5-2667 v4 3.2GHz 8-core CPUs, 64GB DDR4, and MegaRAID 9361-8i controller

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed3.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores8-Core Processor
  • 36 hot-swap 3.5" drive bays for massive storage density
  • Dual Xeon E5-2667 v4 8-core processors at 3.2 GHz base clock
  • 64 GB DDR4 2400 MHz registered ECC memory installed
  • MegaRAID 9361-8i controller with 1 GB cache and battery backup
  • Quad 10GBase-T LAN ports via Intel X540 controller

Supermicro 36-Bay 4U Storage Server

This 4U rackmount system delivers high-density storage with 36 hot-swap 3.5-inch drive bays supporting SATA and SAS drives. Dual Xeon E5-2667 v4 processors at 3.2 GHz provide 16 total cores for demanding workloads. The MegaRAID 9361-8i controller handles RAID 0, 1, 5, 6, 10, 50 and 60 with 1 GB cache and battery backup. Quad 10GBase-T ports and IPMI 2.0 management complete the enterprise feature set.

Suited for archival, backup

The 36-bay capacity and redundant 1280 W platinum power supplies fit organisations that need massive raw capacity in a single chassis. Buyers who need GPU acceleration or more than eight internal RAID ports will not find those interfaces here. The system ships without front bezel or rack rails, so those items must be sourced separately.

36 hot-swap 3.5-inch drive bays define the storage

No drives are included, so the usable capacity depends entirely on the SATA or SAS drives selected. The 9361-8i controller supports up to eight direct SAS/SATA connections, while the remaining bays require expander backplane routing. Maximum memory reach is 3 TB with LRDIMMs or 1.5 TB with RDIMMs across 24 DDR4 slots.

Puntos fuertes

  • 36 hot-swap 3.5" drive bays for massive storage density
  • Dual Xeon E5-2667 v4 8-core processors at 3.2 GHz base clock
  • 64 GB DDR4 2400 MHz registered ECC memory installed
  • MegaRAID 9361-8i controller with 1 GB cache and battery backup
  • Quad 10GBase-T LAN ports via Intel X540 controller

Especificaciones

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed3.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores8-Core Processor
# of Processors InstalledE5-2667 V4
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Preguntas sobre este artículo

How much power do the two 1280W Platinum supplies draw when the dual 145W Xeon E5-2667 v4 CPUs and 36 drives run continuously?

Each CPU is rated at 145W TDP and the system includes two 1280W 80 Plus Platinum redundant hot-swap power supplies designed for continuous operation under full load.

Which rails and front bezel must I source separately to mount this 4U chassis in a standard rack?

The supplier notes that front bezel and rack mount rails are not included, so you will need to obtain compatible 4U rails and a bezel for your rack.

Will the LSI MegaRAID 9361-8i controller recognise the SAS3 backplane used by the 36 hot-swap bays?

The installed 9361-8i is an 8-port 12Gb/s SAS RAID controller with 1GB cache and battery backup, supporting RAID 0, 1, 5, 6, 10, 50 and 60 on the SAS/SATA backplane.
