Small black tall mini PC barebone with Intel Core Ultra 5 125H processor

ASUS

ASUS RNUC14RVHU50000UI NUC 14 Pro barebone mini PC Core Ultra 5 125H

SKU CH-35VP-XYN9G MPN RNUC14RVHU50000UI

Barebone mini PC with Intel Core Ultra 5 125H, triple storage slots, Thunderbolt 4, Wi-Fi 6E and Bluetooth 5.3, memory and storage sold separately

  • ColorBlack
  • Form FactorTall
  • AI FeaturesHarnesses the prowess of Intel Core Ultra processors’ three
  • CPU TypeIntel Core Ultra 5 125H
  • Memory installedNo Memory
  • Memory slot2 x 262Pin SO-DIMM

CPU Type Intel Core Ultra 5 125H

Options Tall

  • AI-ready performance from three Intel AI engines
  • Core Ultra 5 125H with Intel Arc graphics built in
  • Triple-storage design: 2.5" SATA plus two M.2 NVMe slots
  • Wi-Fi 6E and Bluetooth 5.3 with Intel AX211
  • Toolless chassis for fast memory and storage upgrades

ASUS NUC 14 Pro Tall Barebone

The ASUS NUC 14 Pro RNUC14RVHU50000UI is a tall barebone mini PC built around the Intel Core Ultra 5 125H processor. It targets builders who want a compact system with integrated Arc graphics and three AI engines for local inference workloads. Memory and storage are not included, so the buyer supplies DDR5 SO-DIMMs and up to three drives.

Thermals Noise and Power in Normal Use

The 4.61 x 4.41 x 2.13 inch chassis uses a toolless design for quick access to the cooling assembly. In typical desktop workloads the single fan runs quietly while the 125H processor stays within its base power envelope. Sustained multi-core or AI tasks will raise fan speed and surface temperature, but the compact vapour-chamber layout keeps throttling minimal.

What the Bundled Accessories Change

The box includes a cable-locking arm and a VESA mount bracket for securing the unit behind a display. No memory, storage, operating system or power cord are supplied, so the builder must provide DDR5 5600 SO-DIMMs, an M.2 2280 NVMe drive, an optional M.2 2242 NVMe drive and a 2.5 inch SATA drive. Buyers who need a complete out-of-the-box system should choose a pre-configured model instead.

Points forts

  • AI-ready performance from three Intel AI engines
  • Core Ultra 5 125H with Intel Arc graphics built in
  • Triple-storage design: 2.5" SATA plus two M.2 NVMe slots
  • Wi-Fi 6E and Bluetooth 5.3 with Intel AX211
  • Toolless chassis for fast memory and storage upgrades

Caractéristiques

BrandASUS
SeriesNUC 14 Pro
ModelRNUC14RVHU50000UI
Part Number90AR0072-M000M0
ColorBlack
Form FactorTall
AI FeaturesHarnesses the prowess of Intel Core Ultra processors’ three AI engines for high throughput, low power, and fast response
CPU TypeIntel Core Ultra 5 125H
Memory installedNo Memory
Memory slot2 x 262Pin SO-DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported96GB
Serial ATA1 x SATA 6.0Gb/s
M.2 Slot1 x M.2 2280 PCIe Gen4x4 NVMe SSD Slot
1 x M.2 2242 PCIe x4 NVMe SSD Slot
Integrated GraphicsIntel Arc Graphics
LANIntel i226V
Max LAN Speed2.5Gbps
Wireless LANIntel AX211
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.3
2.5" Internal Bays1 x 2.5" SATA
Front USB1 x USB 3.2 Gen2x2 Type-C
2 x USB 3.2 Gen2 Type-A
HDMI2 x HDMI 2.1
Rear USB2 x Thunderbolt 4 (DP2.1 & USB4)
1 x USB 3.2 Gen2 Type-A
1 x USB 2.0 Type-A
RJ451 x Intel 2.5G LAN (RJ45)
Other Rear Ports1 x Cable Locking Arm
1 x DC-in
Power Supply120W AC Adapter
Dimensions4.61" x 4.41" x 2.13"
Weight1.36 lbs.
PackagingUS Cord for USA
Poids d’expédition1.54 kg
Dimensions du colis191 × 178 × 127 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install memory in the toolless chassis, and which notch position do the SO-DIMMs need?

Remove the top cover by hand, insert each DDR5 5600 module into the 262-pin SO-DIMM slots at a slight angle until the clips click, matching the key notch on the stick to the slot.

What storage drives will need attention later, and how many bays are free for expansion?

The 2.5-inch SATA bay and both M.2 slots (2280 PCIe Gen4x4 and 2242 PCIe x4) are empty, so any SSD or hard drive you add becomes the only maintenance item.

At what point does the 2.5 GbE Intel i226V port become the bottleneck during sustained transfers?

Continuous reads or writes faster than 2.5 Gbps will saturate the single RJ45 link before the CPU or Thunderbolt 4 interfaces reach their limits.
