Silver 2U rack server with front bezel, eight 2.5-inch drive bays and dual power supplies

DELL

Dell PowerEdge R730 2U Rack Server 2x Xeon E5-2660 v3 2.6GHz 10-Core 128GB DDR4 H730 8x 2.4TB SAS

SKU CH-XT27-QK63P

A 2U rack server with dual 10-core Xeon processors, 128GB DDR4 memory, a PERC H730 RAID controller and eight 2.4TB SAS drives

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.60 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 128GB

HDD 8 x 2.4TB 10K SAS

  • Dual Xeon E5-2660 v3 CPUs deliver 20 cores at 2.6 GHz with 3.3 GHz turbo
  • 128 GB DDR4 registered ECC memory across 8 modules supports up to 1.5 TB capacity
  • PERC H730 controller enables RAID 0, 1, 5, 6, 10, 50 and 60 with battery-backed cache
  • Eight 2.4 TB 10K SAS drives provide high-capacity 12 Gb/s storage in 2.5" bays
  • Quad-port X520/I350 card adds two 1 GbE and two 10 Gb SFP+ network connections

Dual-socket Xeon rack server for virtualization

The Dell PowerEdge R730 is a 2U rack server built for midsize and large enterprise workloads such as data warehousing, e-commerce, virtual desktop infrastructure and high-performance computing nodes. Two Intel Xeon E5-2660 v3 processors deliver 20 cores at 2.6 GHz with 3.3 GHz turbo, while 128 GB of DDR4 registered ECC memory across eight 16 GB modules supports memory-intensive applications.

Hot-swap drive bays and rails simplify rack

Eight 2.5-inch SAS drive bays accept the included 2.4 TB 10K enterprise drives and connect to the PERC H730 controller with 1 GB cache for RAID 0, 1, 5, 6, 10, 50 and 60. Redundant 750 W platinum power supplies and ready rails are installed, but the chassis depth requires a four-post rack; two-post racks will not provide adequate support.

Verify rack depth, network cabling

Confirm the cabinet depth accommodates the 2U form factor with cable clearance for the quad-port X520/I350 daughter card providing two 1 GbE and two 10 Gb SFP+ links. The system has 24 DDR4 slots with a 1.5 TB maximum, so plan future memory upgrades within registered ECC specifications. iDRAC 8 Enterprise enables remote management once networked.

Points forts

  • Dual Xeon E5-2660 v3 CPUs deliver 20 cores at 2.6 GHz with 3.3 GHz turbo
  • 128 GB DDR4 registered ECC memory across 8 modules supports up to 1.5 TB capacity
  • PERC H730 controller enables RAID 0, 1, 5, 6, 10, 50 and 60 with battery-backed cache
  • Eight 2.4 TB 10K SAS drives provide high-capacity 12 Gb/s storage in 2.5" bays
  • Quad-port X520/I350 card adds two 1 GbE and two 10 Gb SFP+ network connections

Caractéristiques

BrandDELL
SeriesPowerEdge R730
ModelR730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.60 GHz
CPU SocketLGA 2011-3
Number of CPU Cores10-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How can I confirm the dual Xeon E5-2660 v3 processors and 128GB DDR4 are recognised after installation?

Power on the server and open the iDRAC 8 Enterprise interface or enter the BIOS; both will display two 10-core CPUs at 2.6 GHz and 128 GB of registered ECC DDR4 across the 24 DIMM slots.

Which drives, rails and bezel are included and what must I source separately?

The unit ships with eight 2.4 TB 10K SAS 2.5-inch drives, a PERC H730 1 GB controller with battery, ready rails and a front bezel; additional drives, SFP+ transceivers for the 10 GbE ports or extra memory modules are not included.

Which memory configuration matches the installed 128GB DDR4 and allows future expansion?

The system arrives with eight 16 GB DDR4 2133 MHz registered ECC modules occupying 8 of 24 slots, leaving 16 slots free to reach the 1.5 TB maximum using identical DDR4 RDIMMs.
