Rectangular U.2 15mm enterprise SSD with silver metal casing and label showing 15.36TB capacity

Solidigm

Solidigm D7-PS1010 SB5PH27X153TOP1 15.36TB enterprise SSD

SKU CH-8S32-H30P4 MPN SB5PH27X153TOP1

U.2 15mm enterprise SSD with 15.36TB of 176L TLC 3D NAND, PCIe 5.0 interface, 14500 MB/s sequential read, 9300 MB/s sequential write, 2750000 random read IOPS, 380000 random write IOPS.

  • Form FactorU.2 15mm
  • Capacity15.36TB
  • Memory Components176L TLC 3D NAND
  • InterfacePCI-Express 5.0
  • Max Sequential ReadUp to 14500 MBps
  • Max Sequential WriteUp to 9300 MBps

Option 15.36TB U.2 Opal

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Massive 15.36TB capacity consolidates large datasets onto a single U.2 drive
  • PCIe 5.0 interface delivers up to 14500 MB/s sequential reads for throughput-heavy workloads
  • 2,750,000 random read IOPS accelerates database and virtualisation performance
  • 1 DWPD endurance with 28 PBW supports sustained write-intensive applications
  • 176-layer TLC 3D NAND enables high density and power efficiency in 15mm form factor

Capacity and form factor

The Solidigm D7-PS1010 is a 15.36TB enterprise SSD built in the U.2 15mm form factor for data-centre servers. It targets organisations that need high-capacity flash storage for read-intensive workloads such as content delivery, analytics or warm-tier archiving. Buyers who require a 2.5-inch 7mm drive or a consumer M.2 module cannot use this part.

Interface and throughput

The drive connects through a PCI-Express 5.0 x4 link and delivers up to 14500 MBps sequential read and 9300 MBps sequential write. Random performance reaches 2750000 IOPS read and 380000 IOPS write at 4K block size. This bandwidth profile matches platforms that can saturate a Gen 5.0 lane; systems limited to earlier PCIe generations will not realise the rated throughput.

Power and thermal envelope

Idle power draw is 5W and active consumption peaks at 23W within an operating range of 0°C to 77°C. The 176L TLC 3D NAND and controller are rated for 2500000 hours MTBF and 1 DWPD endurance. Shock tolerance is 1000 G at 0.5 msec and vibration limits are 2.17 GRMS operating and 3.13 GRMS non-operating.

Points forts

  • Massive 15.36TB capacity consolidates large datasets onto a single U.2 drive
  • PCIe 5.0 interface delivers up to 14500 MB/s sequential reads for throughput-heavy workloads
  • 2,750,000 random read IOPS accelerates database and virtualisation performance
  • 1 DWPD endurance with 28 PBW supports sustained write-intensive applications
  • 176-layer TLC 3D NAND enables high density and power efficiency in 15mm form factor

Caractéristiques

BrandSolidigm
ModelD7-PS1010
Part NumberSB5PH27X153TOP1
Form FactorU.2 15mm
Capacity15.36TB
Memory Components176L TLC 3D NAND
InterfacePCI-Express 5.0
Max Sequential ReadUp to 14500 MBps
Max Sequential WriteUp to 9300 MBps
4KB Random Read2750000 IOPS (4K Blocks)
4KB Random Write380000 IOPS (4K Blocks)
Endurance1 DWPD / 28 PBW
MTBF2,500,000 hours
SecurityOpal
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C to 77°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight165g +/- 10g
Poids d’expédition0.17 kg
Dimensions du colis140 × 110 × 17 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What does 14500 MBps sequential read look like in a real server workload?

The drive delivers up to 14500 MBps sequential read and 9300 MBps sequential write over PCI-Express 5.0, with 2750000 IOPS random read and 380000 IOPS random write for 4K blocks.

What does PCI-Express 5.0 x4 cap in practice for this drive?

The PCI-Express 5.0 interface supports the rated 14500 MBps read and 9300 MBps write; actual throughput depends on the host controller and slot configuration.

What physical slot and clearance does the U.2 15mm form factor need?

It fits a U.2 15mm bay, weighs 165 g, and operates from 0°C to 77°C with 23 W active power.
