Rectangular silver enterprise SSD with U.2 15mm connector and label showing 3.2TB capacity

Solidigm

Solidigm D7-PS1030 3.2TB U.2 15mm PCIe 5.0 enterprise SSD (SB5PH27E032TOF1)

SKU CH-DCVJ-481RN MPN SB5PH27E032TOF1

Enterprise U.2 15mm PCIe 5.0 SSD with 3.2TB 176L TLC NAND, 14500 MBps read, 8200 MBps write, 3 DWPD endurance and FIPS security

  • Form FactorU.2 15mm
  • Capacity3.2TB
  • Memory Components176L TLC 3D NAND
  • InterfacePCI-Express 5.0
  • Max Sequential ReadUp to 14500 MBps
  • Max Sequential WriteUp to 8200 MBps

Option 3.2TB U.2 FIPS

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Sustains heavy write workloads with 3 DWPD endurance rating
  • Delivers fast data access at 3100000 IOPS random read
  • Secures sensitive data with FIPS certification
  • Fits dense server bays using U.2 15mm form factor
  • Handles demanding environments with 2500000 hours MTBF

Solidigm D7-PS1030 3.2TB U.2 15mm enterprise SSD

The Solidigm D7-PS1030 is a 3.2TB enterprise solid-state drive built for data-centre servers. It uses a U.2 15mm form factor with a PCI-Express 5.0 x4 interface and 176L TLC 3D NAND. The drive delivers up to 14500 MBps sequential read and 8200 MBps sequential write speeds. It is suited to organisations running heavy read-intensive workloads.

Upgrade from PCIe 4.0 or lower-capacity U.2 drives

Moving from a PCIe 4.0 U.2 SSD doubles the interface bandwidth, raising sequential read potential to 14500 MBps and random read to 3100000 IOPS. The jump is worth it when current storage saturates the bus during database scans, analytics or virtualisation I/O. If existing drives already meet latency and throughput targets, the upgrade yields diminishing returns.

3.2TB capacity with 3 DWPD endurance

The 3.2TB capacity handles large datasets, write-heavy logging tiers and mixed read-write caches with 17.5 PBW total endurance. Random write performance of 716000 IOPS sustains transactional databases and checkpointing. Workloads exceeding 3 DWPD or needing more than 3.2TB per drive will require additional units or higher-capacity models.

Points forts

  • Sustains heavy write workloads with 3 DWPD endurance rating
  • Delivers fast data access at 3100000 IOPS random read
  • Secures sensitive data with FIPS certification
  • Fits dense server bays using U.2 15mm form factor
  • Handles demanding environments with 2500000 hours MTBF

Caractéristiques

BrandSolidigm
ModelD7-PS1030
Part NumberSB5PH27E032TOF1
Form FactorU.2 15mm
Capacity3.2TB
Memory Components176L TLC 3D NAND
InterfacePCI-Express 5.0
Max Sequential ReadUp to 14500 MBps
Max Sequential WriteUp to 8200 MBps
4KB Random Read3100000 IOPS (4K Blocks)
4KB Random Write716000 IOPS (4K Blocks)
Endurance3 DWPD / 17.5 PBW
MTBF2,500,000 hours
SecurityFIPS
Power Consumption (Idle)5W
Power Consumption (Active)19W
Operating Temperature0°C to 77°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight140g +/- 10g
Poids d’expédition0.17 kg
Dimensions du colis140 × 110 × 17 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What U.2 backplane or drive bay does the 15mm D7-PS1030 need?

The drive uses a U.2 15mm form factor and connects through a PCI-Express 5.0 x4 interface, so it requires a U.2 backplane or bay wired for PCIe 5.0 x4 signalling.

Which step is most often missed when installing this SSD in a server?

Installers frequently forget to verify that the backplane and system BIOS both support PCI-Express 5.0 x4 lane allocation before seating the drive.

When will the 3.2TB drive reach its rated write endurance of 17.5 PBW?

At the rated 3 DWPD, the 17.5 PBW endurance limit is reached after five years of writing the full 3.2TB capacity every day.
