Rectangular silver U.2 15mm enterprise SSD with label showing 12.8TB capacity

Solidigm

Solidigm D7-PS1030 SB5PH27E128TOF1 12.8TB U.2 15mm PCIe 5.0 enterprise SSD

SKU CH-WRYR-56QNM MPN SB5PH27E128TOF1

12.8TB U.2 15mm PCIe 5.0 enterprise SSD delivering 14500 MBps read, 9300 MBps write and 3 DWPD endurance with FIPS security

  • Form FactorU.2 15mm
  • Capacity12.8TB
  • Memory Components176L TLC 3D NAND
  • InterfacePCI-Express 5.0
  • Max Sequential ReadUp to 14500 MBps
  • Max Sequential WriteUp to 9300 MBps

Option 12.8TB U.2 FIPS

Les versions barrées existent, mais ne sont pas disponibles ici.

  • 8TB capacity stores massive datasets on a single U.2 15mm drive
  • Sequential read up to 14500 MBps accelerates large-file workflows
  • 2750000 random read IOPS handles heavy transactional workloads
  • 3 DWPD endurance with 70 PBW rating sustains write-intensive applications
  • FIPS security protects sensitive data at rest

Enterprise U.2 15mm SSD

The Solidigm D7-PS1030 is a 12.8TB enterprise solid-state drive built for data-centre servers and high-density storage arrays. It uses 176L TLC 3D NAND and a PCIe 5.0 x4 interface to deliver sustained performance in write-intensive workloads. The drive carries FIPS security validation and a 3 DWPD endurance rating. It targets IT teams that need large capacity with consistent low latency.

PCIe 5.0 x4 interface

The single specification that decides fit is the PCIe 5.0 x4 U.2 15mm connector. The host system must provide a compatible U.2 backplane or riser with PCIe 5.0 signalling and 15mm drive bays. Without that physical and electrical match the drive cannot be installed or will fall back to lower speeds. Verify the platform slot specification before purchase.

12.8TB capacity with 70 PBW endurance

At 12.8TB the drive comfortably holds large databases, virtualisation images and analytics datasets while sustaining up to 14500 MBps sequential read and 9300 MBps sequential write. Random performance reaches 2750000 read IOPS and 800000 write IOPS at 4K blocks. The 70 PBW write budget supports the rated 3 DWPD across the warranty period; workloads exceeding that write volume will consume endurance faster than planned.

Points forts

  • 8TB capacity stores massive datasets on a single U.2 15mm drive
  • Sequential read up to 14500 MBps accelerates large-file workflows
  • 2750000 random read IOPS handles heavy transactional workloads
  • 3 DWPD endurance with 70 PBW rating sustains write-intensive applications
  • FIPS security protects sensitive data at rest

Caractéristiques

BrandSolidigm
ModelD7-PS1030
Part NumberSB5PH27E128TOF1
Form FactorU.2 15mm
Capacity12.8TB
Memory Components176L TLC 3D NAND
InterfacePCI-Express 5.0
Max Sequential ReadUp to 14500 MBps
Max Sequential WriteUp to 9300 MBps
4KB Random Read2750000 IOPS (4K Blocks)
4KB Random Write800000 IOPS (4K Blocks)
Endurance3 DWPD / 70 PBW
MTBF2,500,000 hours
SecurityFIPS
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C to 77°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight165g +/- 10g
Poids d’expédition0.17 kg
Dimensions du colis140 × 110 × 17 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What does the 14500 MBps sequential read figure deliver once the drive is installed in a server?

It enables rapid loading of large datasets and fast boot times for virtualised workloads, limited by the PCIe 5.0 x4 link and the host controller.

How does the PCIe 5.0 x4 interface cap real-world throughput?

The x4 lane width sets a theoretical ceiling near 14500 MBps read and 9300 MBps write; actual speeds depend on CPU lane allocation and thermal headroom.

What physical space and mounting does the U.2 15mm form factor require?

It needs a 2.5-inch U.2 hot-swap bay with 15mm vertical clearance and a compatible backplane connector for power and data.
