Rectangular U.2 15mm enterprise SSD with silver metal casing and gold edge connector

Solidigm

Solidigm SB5PH27E032TOP1 D7-PS1030 3.2TB U.2 15mm PCIe 5.0 enterprise SSD

SKU CH-HKVX-V6S15 MPN SB5PH27E032TOP1

Enterprise U.2 15mm SSD delivering 3.2TB capacity with PCIe 5.0 speeds up to 14500 MB/s read and 8200 MB/s write

  • Form FactorU.2 15mm
  • Capacity3.2TB
  • Memory Components176L TLC 3D NAND
  • InterfacePCI-Express 5.0
  • Max Sequential ReadUp to 14500 MBps
  • Max Sequential WriteUp to 8200 MBps

Option 3.2TB U.2 Opal

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Up to 14500 MBps sequential read accelerates large-file workflows
  • 1 million random read IOPS keeps database queries responsive
  • 2 TB capacity with 3 DWPD endurance sustains heavy write workloads
  • PCIe 5.0 x4 interface doubles bandwidth over previous-gen buses
  • 5 million hour MTBF supports continuous data-centre operation

Enterprise SSD for data-centre workloads

The Solidigm D7-PS1030 is a 3.2TB U.2 15mm drive built on 176L TLC 3D NAND and a PCI-Express 5.0 x4 interface. It targets servers and storage arrays that need high throughput and consistent low latency for mixed read and write workloads.

Opal security and enterprise endurance

Hardware-based Opal encryption protects data at rest without host software overhead. The drive is rated for 3 DWPD and 17.5 PBW, with a 2,500,000-hour MTBF, so it sustains heavy write cycles day after day in always-on environments.

Sequential and random performance headroom

Sequential reads reach 14500 MBps and writes 8200 MBps, while 4KB random reads hit 3100000 IOPS and writes 716000 IOPS. Active power draws 19W and idle 5W within a 0°C to 77°C operating range. Workloads demanding higher capacity or lower power per terabyte will need additional drives.

Points forts

  • Up to 14500 MBps sequential read accelerates large-file workflows
  • 1 million random read IOPS keeps database queries responsive
  • 2 TB capacity with 3 DWPD endurance sustains heavy write workloads
  • PCIe 5.0 x4 interface doubles bandwidth over previous-gen buses
  • 5 million hour MTBF supports continuous data-centre operation

Caractéristiques

BrandSolidigm
ModelD7-PS1030
Part NumberSB5PH27E032TOP1
Form FactorU.2 15mm
Capacity3.2TB
Memory Components176L TLC 3D NAND
InterfacePCI-Express 5.0
Max Sequential ReadUp to 14500 MBps
Max Sequential WriteUp to 8200 MBps
4KB Random Read3100000 IOPS (4K Blocks)
4KB Random Write716000 IOPS (4K Blocks)
Endurance3 DWPD / 17.5 PBW
MTBF2,500,000 hours
SecurityOpal
Power Consumption (Idle)5W
Power Consumption (Active)19W
Operating Temperature0°C to 77°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight140g +/- 10g
Poids d’expédition0.17 kg
Dimensions du colis140 × 110 × 17 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

When will the 3 DWPD endurance rating or 17.5 PBW write budget require drive replacement?

At 3 DWPD the 3.2TB drive can absorb 17.5 PBW of host writes; once that budget is exhausted the NAND reaches its warranted wear limit and the unit should be swapped.

Which spec caps sustained throughput first — the PCIe 5.0 x4 link or the controller 14500 MBps read ceiling?

The controller tops out at 14500 MBps sequential read and 8200 MBps sequential write, so the silicon limit arrives before the PCIe 5.0 x4 bus saturates.

What are the steady-state power draw and temperature envelope when the SSD runs continuously at 19W active power?

Active power is 19W and the operating range is 0°C to 77°C; sustained loads keep the drive inside that thermal window without exceeding the rated power.
