Black 14-inch all-in-one industrial panel PC with flat touchscreen and fanless aluminium chassis

partaker

Partaker Z10-I7 1165G7-8G128G 14" all-in-one PC

SKU CH-QRKN-6CJV1

A 14" IP65-rated industrial all-in-one with a 10-point capacitive touchscreen, Core i7-1165G7, 8GB DDR4 and 128GB SSD running Windows 11 Pro

  • Form FactorAll-in-One
  • ColorBlack
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 11th Gen
  • CPU NameIntel Core i7-1165G7
  • GPU/VGA TypeIntel Iris Xe Graphics

CPU Type Intel Core i7 11th Gen

CPU Name Intel Core i7-1165G7

GPU Intel Iris Xe Graphics

Memory 8GB DDR4

  • 16GB DDR4
  • 32GB DDR4
  • 64GB DDR4
  • 8GB DDR4

SSD 128GB

취소선으로 표시된 버전은 존재하지만, 이곳에서는 취급하지 않습니다.

  • Fanless aluminium chassis runs 0 to 50 °C without moving parts
  • IP65 front panel resists dust and water jets in harsh environments
  • 10-point capacitive touchscreen rated for 200 million touches
  • Core i7-1165G7 with 8 GB DDR4 and 128 GB SSD for industrial workloads
  • Dual LAN, HDMI, VGA, 4 USB and 2 COM ports for flexible integration

Industrial 14″ panel PC for harsh environments

The Partaker Z10-I7 1165G7-8G128G is a fanless all-in-one computer built around a 14″ TFT LED display with IP65 front protection. It runs Windows 11 Pro on an Intel Core i7-1165G7 processor with 8GB DDR4-3200 memory and a 128GB SSD. The 10-point projected capacitive touchscreen is rated for 200 million touches and operates from 0 to 50°C, making it suitable for embedded, wall-mounted, desktop or cantilevered installation in industrial or commercial settings.

Dual storage bays and wireless expansion slots

One M.2 2260/2280 slot supports PCIe x1 or SATA SSD, while a 2.5″ SATA bay accepts an additional SSD or HDD. An M.2 Key E slot is ready for a WiFi 6 module and an M.2 Key B slot with SIM holder accepts a 5G module, so connectivity can be upgraded without replacing the unit. The package includes a power adapter and mounting kits for immediate deployment.

Limited screen resolution and legacy video outputs

The display resolution is 1600 x 900 with 200 cd/m² brightness and a 400:1 contrast ratio, which may not suit detailed visual inspection or bright ambient light. Video output is restricted to HDMI and VGA, so modern high-refresh or high-resolution external monitors cannot be driven at their native settings. The fanless aluminium chassis limits sustained turbo performance under heavy continuous loads.

주요 특징

  • Fanless aluminium chassis runs 0 to 50 °C without moving parts
  • IP65 front panel resists dust and water jets in harsh environments
  • 10-point capacitive touchscreen rated for 200 million touches
  • Core i7-1165G7 with 8 GB DDR4 and 128 GB SSD for industrial workloads
  • Dual LAN, HDMI, VGA, 4 USB and 2 COM ports for flexible integration

사양

ModelZ10-I7 1165G7-8G128G
Form FactorAll-in-One
ColorBlack
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 11th Gen
CPU NameIntel Core i7-1165G7
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity8GB DDR4
SSD128GB
HDDNo
Screen Size14"
TouchscreenYes

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

What is the rated backlight lifespan of the 14" TFT LED panel?

The panel backlight is rated for a minimum of 10,000 hours of operation.

At what temperature does the system throttle or shut down under sustained load?

The fanless aluminium chassis is rated for continuous operation up to 50 °C ambient with the installed SSD.

How much power does the external supply draw when the unit runs all day?

The included adapter accepts 100–240 V AC input and delivers 12 V DC to the fanless system.
