Gray 15-inch industrial all-in-one PC with IP65 front panel and projected capacitive touchscreen

partaker

partaker A23 all-in-one PC 15" IP65 i7-8565U 16GB 512GB

SKU CH-9FE0-MFYY0

A 15-inch IP65-rated industrial all-in-one with a 10-point capacitive touchscreen, Core i7-8565U, 16GB DDR4, 512GB SSD and fanless aluminium cooling for 24/7 operation

  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 8th Gen
  • CPU NameIntel Core i7-8565U
  • GPU/VGA TypeIntel UHD Graphics

CPU Type Intel Core i7 8th Gen

CPU Name Intel Core i7-8565U

GPU Intel UHD Graphics

Memory 16GB DDR4

SSD 512GB

취소선으로 표시된 버전은 존재하지만, 이곳에서는 취급하지 않습니다.

  • IP65 front protection seals out dust and water jets
  • 10-point capacitive touch handles gloved or wet-finger input
  • Intel Core i7-8565U with 16 GB DDR4 runs automation tasks smoothly
  • Fanless aluminium chassis operates silently in continuous 24/7 duty
  • 12 V DC input plus HDMI, VGA, dual LAN and dual COM simplifies industrial integration

Industrial Panel PC with IP65 Front

The Partaker A23 is a 15-inch all-in-one computer rated IP65 on the front panel for dust and water-jet protection. It runs an Intel Core i7-8565U processor with 16GB DDR4 memory and a 512GB SSD under Windows 11 Pro. The fanless aluminium chassis operates silently from 0 to 50°C, making it suitable for continuous industrial use.

Suited for embedded automation

This unit fits machine interfaces, SCADA nodes and kiosk deployments that need a sealed 10-point capacitive touchscreen, dual LAN, dual COM ports and 12V DC power. Buyers who require a larger display, higher resolution than 1024x768, or active cooling for sustained heavy workloads should consider other form factors.

15-inch 1024x768 IP65 touchscreen

The 15-inch TFT LED panel delivers 1024x768 resolution with 350cd/m2 brightness and a 1000:1 contrast ratio. Ten-point projected capacitive touch supports glove and wet-finger operation, while the IP65-rated front bezel withstands wash-down and dust ingress in food, pharmaceutical or outdoor cabinet installations.

주요 특징

  • IP65 front protection seals out dust and water jets
  • 10-point capacitive touch handles gloved or wet-finger input
  • Intel Core i7-8565U with 16 GB DDR4 runs automation tasks smoothly
  • Fanless aluminium chassis operates silently in continuous 24/7 duty
  • 12 V DC input plus HDMI, VGA, dual LAN and dual COM simplifies industrial integration

사양

ModelA23-I7 8565U-16G512G
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 8th Gen
CPU NameIntel Core i7-8565U
GPU/VGA TypeIntel UHD Graphics
Memory Capacity16GB DDR4
SSD512GB
HDDNo
Screen Size15"
TouchscreenYes

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

Can I keep using my current 12V DC power supply with the A23's DC input?

The unit accepts 100-240V AC via the included adapter and provides a 12V DC input on the panel, so your existing 12V supply can connect directly if it matches the barrel connector and polarity.

How do I confirm the 10-point capacitive touch and 1024x768 panel are working after installation?

Open Windows Settings > Bluetooth & devices > Touch and run the calibration tool; the display should report 1024x768 resolution and register all ten simultaneous touch points.

What ships in the box and which storage drives must I add myself?

The package contains the A23 panel PC, AC-to-12V power supply, and power cord. The 512GB SSD is pre-installed; the empty mSATA, M.2 2280, and 2.5" SATA bays are available for additional drives you purchase separately.
