14 inch black all in one panel PC with IP65 touchscreen

partaker

Partaker Z10 Industrial Panel PC 14" i7-8565U 32GB DDR4 512GB

SKU CH-7B71-Z9DTW

A fanless 14-inch IP65 industrial all-in-one with a 10-point capacitive touchscreen, Core i7-8565U, 32GB DDR4 and 512GB SSD

  • Form FactorAll-in-One
  • ColorBlack
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 8th Gen
  • CPU NameIntel Core i7-8565U
  • GPU/VGA TypeIntel UHD Graphics

CPU Type Intel Core i7 8th Gen

CPU Name Intel Core i7-8565U

GPU Intel UHD Graphics

Memory 32GB DDR4

SSD 512GB

  • 256GB
  • 512GB
  • 1TB
  • 128GB

취소선으로 표시된 버전은 존재하지만, 이곳에서는 취급하지 않습니다.

  • 14-inch IP65 front panel resists dust and water jets
  • Intel Core i7-8565U quad-core up to 4.6 GHz drives industrial workloads
  • 32 GB DDR4-2400 memory with 512 GB SSD for fast data access
  • Fanless aluminium chassis operates silently from 0 to 50 °C
  • 10-point capacitive touchscreen rated for 200 million touches

Industrial 14-inch Panel PC

The Partaker Z10 is a fanless all-in-one computer with a 14-inch IP65-rated touchscreen, Intel Core i7-8565U processor, 32GB DDR4 memory and a 512GB SSD. It ships with Windows 11 Pro and targets factory automation, kiosk and machine-interface deployments that need a sealed front panel. The aluminium chassis operates from 0 to 50°C without moving parts.

Upgrade from legacy panel PCs

This unit replaces older fan-cooled or non-IP65 panel PCs where dust, moisture or vibration cause failures. The jump is worth it when an application needs 10-point projected capacitive touch rated for 200 million touches, triple internal storage bays (mSATA, M.2 2280, 2.5-inch SATA) and dual LAN plus two COM ports for PLC connectivity. Buyers who need a larger display or PCIe expansion slots should look elsewhere.

Embedded mounting and wiring

Installation uses the 340.3 x 225.3 mm cut-out for embedded mounting, with wall, desktop or cantilever options also supported. The 12V DC input accepts 100-240V AC via the included adapter. Common issues are routing the two USB 3.0, two USB 2.0, HDMI, VGA, audio and COM cables through tight enclosures, and ensuring the Mini PCIe slot has a compatible 4G or WiFi module if wireless is required.

주요 특징

  • 14-inch IP65 front panel resists dust and water jets
  • Intel Core i7-8565U quad-core up to 4.6 GHz drives industrial workloads
  • 32 GB DDR4-2400 memory with 512 GB SSD for fast data access
  • Fanless aluminium chassis operates silently from 0 to 50 °C
  • 10-point capacitive touchscreen rated for 200 million touches

사양

ModelZ10-I7 8565U-32G512G
Form FactorAll-in-One
ColorBlack
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 8th Gen
CPU NameIntel Core i7-8565U
GPU/VGA TypeIntel UHD Graphics
Memory Capacity32GB DDR4
SSD512GB
HDDNo
Screen Size14"
TouchscreenYes

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

What are the cut-out dimensions for embedding this 14" panel PC?

The opening hole measures 340.3 x 225.3 mm for flush panel mounting.

How do I install the pre-loaded Windows 11 Pro on the Z10, and what step is often missed?

Windows 11 Pro is already installed and activated; the common oversight is skipping the initial OOBE network setup required for Pro features.

When will the 10-point capacitive touchscreen need replacement?

The touch layer is rated for 200 million touches; at heavy industrial use this typically means several years before degradation.
