Compact slim barebone mini PC with matte finish and tool-less chassis

ASUS

ASUS NUC15CRKU5 Core Ultra 5 225H barebone mini PC (Barebone System)

SKU CH-X513-NA0T9 MPN NUC15CRKU5

A slim barebone mini PC with an Intel Core Ultra 5 225H processor, Intel Arc graphics, dual-channel DDR5 support up to 96 GB, dual HDMI 2.1 and Thunderbolt 4 for four 4K displays, 2.5 Gbps LAN.

  • Form FactorSlim
  • AI FeaturesAI Ready
  • CPU TypeIntel Core Ultra 5 225H
  • Memory installedNo Memory
  • Memory slot2 x 262Pin SO-DIMM
  • Memory Type SupportedDDR5 5600

Group Barebone

  • Intel Core Ultra 5 225H with 14 cores up to 4.90 GHz delivers responsive compute for demanding workloads
  • Dual-channel DDR5 5600 support up to 96 GB enables smooth multitasking and heavy data tasks
  • Intel Arc graphics plus dual HDMI 2.1 and Thunderbolt 4 with DisplayPort 2.1 drive up to four 4K displays
  • 48 L tool-less slim chassis allows quick memory and storage upgrades in a compact footprint
  • Wi-Fi 7 and Bluetooth 5.4 with 2.5 Gbps LAN provide fast, low-latency wired and wireless connectivity

Compact barebone for custom builds

The ASUS NUC 15 Pro NUC15CRKU5 is a new 0.48L barebone mini PC built around an Intel Core Ultra 5 225H processor with 14 cores and Intel Arc Graphics. It ships without memory or storage so integrators can choose DDR5-5600 SO-DIMMs up to 96 GB across two slots and two NVMe SSDs in 2280 and 2242 form factors. The platform targets commercial deployments and compact workstations that need Intel vPro manageability.

Display and I/O limits

Quad 4K output is supported through dual HDMI 2.1 ports and a Thunderbolt 4 connection with DisplayPort 2.1 signalling. Wired networking tops out at 2.5 Gbps via the Intel i226V controller, while wireless uses Wi-Fi 7 and Bluetooth 5.4. The single Thunderbolt 4 port shares bandwidth with display traffic, so driving four panels simultaneously reduces available throughput for attached peripherals.

Compatibility checklist

Verify that your SO-DIMMs are 262-pin DDR5 modules rated for 5600 MT/s; other generations will not fit. Confirm both M.2 slots accept NVMe PCIe drives — one 2280 and one 2242 — and that your SSDs match those lengths. Ensure your operating system supports Intel vPro and Arc Graphics drivers for full feature enablement.

Highlights

  • Intel Core Ultra 5 225H with 14 cores up to 4.90 GHz delivers responsive compute for demanding workloads
  • Dual-channel DDR5 5600 support up to 96 GB enables smooth multitasking and heavy data tasks
  • Intel Arc graphics plus dual HDMI 2.1 and Thunderbolt 4 with DisplayPort 2.1 drive up to four 4K displays
  • 48 L tool-less slim chassis allows quick memory and storage upgrades in a compact footprint
  • Wi-Fi 7 and Bluetooth 5.4 with 2.5 Gbps LAN provide fast, low-latency wired and wireless connectivity

Specifications

BrandASUS
SeriesNUC 15 PRO
ModelNUC15CRKU5
Form FactorSlim
AI FeaturesAI Ready
CPU TypeIntel Core Ultra 5 225H
Memory installedNo Memory
Memory slot2 x 262Pin SO-DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported96GB
Dual Channel Memory SupportedYes
Storage InstalledNo Hard Drive
M.2 Slot1 x M.2 2280 NVMe PCIe G4x4 SSD
1 x M.2 2242 NVMe PCIe x4 SSD
Discrete Graphic CardIntel Arc Graphics
Onboard AudioIntegrated
Channel7.1 Channel
LANIntel i226V
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 7
BluetoothBluetooth 5.4
Front USB1 x USB 3.2 Gen2x2 Type-C
2 x USB 3.2 Gen2 Type-A
HDMI2 x HDMI 2.1 (up to 4K@60Hz)
Thunderbolt2 x Thunderbolt 4 (with DP1.4 / 5V/3A, 40Gbps)
Rear USB1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
1 x USB 2.0 Type-A (5V/0.5A, 480Mbps)
RJ451 x Intel 2.5G LAN (RJ45)
Other Rear Ports1 x Kensington
1 x DC-in
Input120W
Dimensions117mm x 112mm x 54mm
Weight1.3 lbs
PackagingVESA Mount & Screws / AC Power Adapter/ Power Cord

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Which DDR5 speed should I pick for the 262-pin SO-DIMM slots to reach the rated 96 GB maximum?

Install DDR5-5600 modules; the board runs them at that speed in dual-channel mode and supports up to 96 GB total across the two slots.

What does the 4.90 GHz boost clock on the 14-core Core Ultra 5 225H mean for everyday workloads?

The 4 P-cores can hit 4.90 GHz for bursty single-thread tasks while the 8 E-cores and 2 low-power E-cores handle background threads, keeping the system responsive under mixed loads.

How many 4K displays can I drive simultaneously over the Thunderbolt 4 and HDMI 2.1 ports?

Up to four 4K displays — two via the HDMI 2.1 ports and two more through the Thunderbolt 4 connection with DisplayPort 2.1 alt-mode.
