Small square tall mini PC barebone chassis with matte finish

ASUS

ASUS NUC15CRHU7 barebone mini PC Intel Core Ultra 7 255H

SKU CH-60DH-HNQ32 MPN NUC15CRHU7

Barebone mini PC with Intel Core Ultra 7 255H, Intel Arc graphics, dual-channel DDR5 support to 96 GB, and Thunderbolt 4 for four 4K displays

  • Form FactorTall
  • AI FeaturesAI Ready
  • CPU TypeIntel Core Ultra 7 225H
  • Memory installedNo Memory
  • Memory slot2 x 262Pin SO-DIMM
  • Memory Type SupportedDDR5 5600

Group Barebone

  • Up to 96 GB dual-channel DDR5 memory for heavy multitasking
  • 16-core Intel Core Ultra 7 255H reaches 5.1 GHz for demanding workloads
  • Intel Arc graphics plus vPro security for professional visual tasks
  • Four 4K displays via dual HDMI 2.1 and Thunderbolt 4
  • 48 L tool-less chassis enables quick upgrades in minimal space

Intel Core Ultra 7 255H barebone

This ASUS NUC 15 Pro barebone system centres on the Intel Core Ultra 7 255H processor with 16 cores and a 5.1 GHz boost clock. It targets professionals and enthusiasts who want a compact, AI-ready platform for multi-display productivity or light content creation. The tall 0.48L chassis leaves memory and storage choices entirely to the builder.

Dual HDMI 2.1 and Thunderbolt 4 connectivity

Two HDMI 2.1 ports and a Thunderbolt 4 port with DisplayPort 2.1 alt-mode enable up to four 4K displays from a single device. Intel vPro technology adds hardware-based security and remote management features for enterprise environments. Wi-Fi 7 and Bluetooth 5.4 provide modern wireless throughput and peripheral support.

96 GB DDR5-6400 ceiling and dual M.2 slots

Two 262-pin SO-DIMM slots accept up to 96 GB of dual-channel DDR5-6400 memory for heavy multitasking. One M.2 2280 and one M.2 2242 slot both support NVMe PCIe Gen 4 x4 SSDs, giving fast primary and secondary storage options. Integrated Intel Arc graphics handle everyday visual workloads but are not suited for high-end 3D rendering or gaming.

Highlights

  • Up to 96 GB dual-channel DDR5 memory for heavy multitasking
  • 16-core Intel Core Ultra 7 255H reaches 5.1 GHz for demanding workloads
  • Intel Arc graphics plus vPro security for professional visual tasks
  • Four 4K displays via dual HDMI 2.1 and Thunderbolt 4
  • 48 L tool-less chassis enables quick upgrades in minimal space

Specifications

BrandASUS
SeriesNUC 15 PRO
ModelNUC15CRHU7
Form FactorTall
AI FeaturesAI Ready
CPU TypeIntel Core Ultra 7 225H
Memory installedNo Memory
Memory slot2 x 262Pin SO-DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported96GB
Dual Channel Memory SupportedYes
Storage InstalledNo Hard Drive
M.2 Slot1 x M.2 2280 NVMe PCIe G4x4 SSD
1 x M.2 2242 NVMe PCIe x4 SSD
Discrete Graphic CardIntel Arc Graphics
Onboard AudioIntegrated
Channel7.1 Channel
LANIntel i226V
Max LAN Speed10/100/1000/2500Mbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 7
BluetoothBluetooth 5.4
Front USB1 x USB 3.2 Gen2x2 Type-C
2 x USB 3.2 Gen2 Type-A
HDMI2 x HDMI 2.1 (up to 4K@60Hz)
Thunderbolt2 x Thunderbolt 4 (with DP1.4 / 5V/3A, 40Gbps)
Rear USB1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
1 x USB 2.0 Type-A (5V/0.5A, 480Mbps)
RJ451 x Intel 2.5G LAN (RJ45)
Other Rear Ports1 x Kensington
1 x DC-in
Input120W
Dimensions117mm x 112mm x 54mm
Weight1.3 lbs
PackagingVESA Mount & Screws / AC Power Adapter/ Power Cord

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What DDR5 memory speed and capacity does the NUC15CRHU7 support for future upgrades?

The board accepts dual-channel DDR5-5600 SO-DIMMs up to 96 GB total across two 262-pin slots.

Which component will hit its thermal or power ceiling first when the Core Ultra 7 255H runs at 5.1 GHz continuously?

The 16-core processor (6P, 8E, 2 low-power E) is the first to reach its thermal limit under sustained all-core load.

How loud and hot does the 0.48 L chassis get when the system runs all day with four 4K displays?

The compact tool-less enclosure relies on an internal fan; sustained quad-4K output raises both noise and surface temperature noticeably.
