ATX motherboard black PCB silver heatsinks RGB lighting pre-mounted I/O shield

ASUS

ASUS ROG Strix H370-F Gaming Intel motherboard

SKU CH-7ENR-RCRWC

ATX motherboard for 8th and 9th Gen Intel Core CPUs on LGA 1151 with Intel H370 chipset, dual M.2 slots, one M.2 heatsink, six SATA 6Gbps ports, USB 3.1 Gen 2 Type-A and Type-C.

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU Type8th generation Intel Core processors * Not backward compatib
  • Supported CPU TechnologiesTurbo Boost Technology 2.0 * The support of these features d
  • ChipsetIntel H370
  • Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support Mu
  • Memory StandardDDR4 2666/ 2400/ 2133 * DDR4 2666MHz memory frequency is onl
  • Ready for 8th Gen Intel Core CPUs on LGA 1151 socket
  • Dual M.2 slots with PCIe 3.0 x4 and x2 modes plus onboard heatsink
  • SupremeFX S1220A 8‑channel audio with Sonic Studio III
  • Intel I219‑V Gigabit LAN with LANGuard protection
  • Aura Sync RGB lighting with dedicated headers and 3D‑print mounts

ROG Strix H370-F Gaming ATX motherboard

The ASUS ROG Strix H370-F Gaming is an ATX motherboard built around the Intel H370 chipset for 8th and 9th Generation Intel Core processors using the LGA 1151 socket. It targets gamers and DIY builders who want a full-size board with RGB lighting and dual M.2 storage slots without overclocking features. The board includes a pre-mounted I/O shield, SupremeFX S1220A audio and Intel I219-V Gigabit LAN.

Check CPU generation and memory speed limits

This board only supports 8th and 9th Generation Intel Core, Pentium Gold and Celeron processors in the LGA 1151 300 Series socket; older LGA 1151 CPUs will not work. DDR4 2666 MHz is supported only with 8th Generation 6-core processors, otherwise modules run at 2400 MHz or 2133 MHz. The chipset does not allow CPU overclocking, so K-series chips run at stock speeds.

Dual M.2 slots and expansion layout

Two M.2 sockets accept 2242, 2260 and 2280 drives; one runs at PCIe 3.0 x4 and the other at PCIe 3.0 x2 or SATA mode, with a heatsink on the first slot. Six SATA 6Gb/s ports handle additional drives. A primary PCIe 3.0 x16 slot takes a graphics card, a second x16 slot runs at x4 and four x1 slots add peripherals. USB 3.1 Gen 2 Type-A and Type-C ports sit on the rear I/O.

Highlights

  • Ready for 8th Gen Intel Core CPUs on LGA 1151 socket
  • Dual M.2 slots with PCIe 3.0 x4 and x2 modes plus onboard heatsink
  • SupremeFX S1220A 8‑channel audio with Sonic Studio III
  • Intel I219‑V Gigabit LAN with LANGuard protection
  • Aura Sync RGB lighting with dedicated headers and 3D‑print mounts

Specifications

BrandASUS
SeriesROG
ModelStrix H370-F Gaming
CPU Socket TypeLGA 1151 (300 Series)
CPU Type8th generation Intel Core processors
* Not backward compatible with older generation of LGA 1151 CPUs
** Refer to www.asus.com for Intel CPU support list
Supported CPU TechnologiesTurbo Boost Technology 2.0
* The support of these features depends on the CPU types.
ChipsetIntel H370
Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support
Multi-VGA output support: DisplayPort/HDMI/DVI-D ports
- Supports DisplayPort* with max. resolution 4096 x 2304@60Hz
- Supports HDMI with max. resolution 4096 x 2160@24Hz / 2560 x 1600@60Hz
- Supports DVI-D with max. resolution 1920 x 1200@60Hz
Maximum shared memory of 1024MB
* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays
Memory StandardDDR4 2666/ 2400/ 2133
* DDR4 2666MHz memory frequency is only supported by 8th Generation Intel 6-core processors. Higher memory modules will run at the maximum transfer rate of DDR4 2666MHz.
** Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please refer to Memory QVL (Qualified Vendors List) for details.
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x168th Generation Intel Core Processor
1 x PCIe 3.0/2.0 x16 slot (supports x16)
Intel H370 Chipset
1 x PCIe 3.0/2.0 x16 slot (max at x4 mode)
PCI Express x14 x PCIe 3.0/2.0 x1 slots
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x2 mode)*
1 x M.2_2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x4 mode)
* The M.2_1 socket shares bandwidth with SATA6G_2 port when using M.2 SATA mode device. Adjust BIOS settings to use X2 mode (PCIE only).
Audio ChipsetROG SupremeFX S1220A High Definition Audio CODEC
Audio Channels8 Channels
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI port
HDMI1 x HDMI
RJ451 x Anti-surge LAN (RJ45) port
DisplayPort1 x DisplayPort
USB 3.13 x USB 3.1 gen2 ports (1 Type-C port [black] + 2 Type-A ports [red])
USB 1.1/2.04 x USB 2.0 ports [black]
S/PDIF Out1 x Optical
Audio Ports5 Ports
Onboard USB2 x USB 3.1 gen1 connectors support additional 4 x USB 3.1 gen1 ports
1 x USB 2.0 connectors support additional 2 x USB 2.0 ports
Other Connectors1 x 4-Pin CPU_FAN connector
1 x 4-Pin CPU_OPT fan connector
1 x 4-Pin AIO_PUMP connector
2 x 4-Pin CHA_FAN connectors
1 x 4-Pin M.2_FAN connector
1 x 5-Pin EXT_FAN connector
1 x System panel connector
1 x Clear CMOS jumper
1 x T_SENSOR header
1 x TPM connector
1 x RGB_HEADER
1 x COM connector
1 x Front panel audio connector (AAFP)
Form FactorATX
LED LightingRGB
Dimensions (W x L)12.0" x 9.6"
Power Pin1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
FeaturesMulti-GPU Support:
Supports AMD 2-Way CrossFireX Technology
ROG Exclusive Features:
Aura
ROG RAMCache II
ROG CPU-Z
ROG CloneDrive
ROG Overwolf
ROG GameFirst IV*
*ROG GameFirst IV is only available for Windows 10 64-bit
ASUS Special Features:
ASUS Exclusive Features:
- AI Suite 3
- Ai Charger
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
ASUS Q-Design:
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
Gamer's Guardian
- SafeSlot
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio, KBMS and USB ports
- Highly Durable Co
Package ContentsAccessories:
User guide
ROG motherboard support DVD
2 x 2-in-1 SATA 6Gb/s cables
1 x Extension Cable for RGB Strips
1 x Cable Ties set
1 x ROG Strix Series sticker
1 x ROG Strix Series Door Hanger
1 x M.2 Screws Package
1 x 3D Printing Mount Package

Questions about this item

Does the Strix H370-F Gaming ship with the I/O shield already fitted and are any cables or drives missing from the box?

The board includes a pre-mounted I/O shield in the retail package. No M.2 SSD, SATA cables or DDR4 modules are supplied, so you must buy those separately.

Which M.2 slot should I use for a 2280 NVMe drive to get the full PCIe 3.0 x4 bandwidth?

Install the drive in the M.2_2 socket; it runs at PCIe 3.0 x4, while M.2_1 is limited to PCIe 3.0 x2 or SATA mode.

What practical difference does the 2666 MHz DDR4 rating make once the board is built?

With an 8th Gen 6-core CPU the memory controller runs at 2666 MHz; faster modules will simply down-clock to that speed.
