ASUS TX Gaming GeForce RTX 5070 graphics card, triple-fan cooler, dark finish

ASUS

ASUS TX Gaming GeForce RTX 5070 OC 12GB GDDR7 graphics card

SKU CH-1JDS-A8EW2

GeForce RTX 5070 graphics card with 12GB GDDR7 memory, 6144 CUDA cores, PCI Express 5.0 and four-display output via HDMI 2.1b and DisplayPort 2.1b

  • InterfacePCI Express 5.0
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5070
  • CUDA Cores6144
  • Effective Memory Clock28 Gbps
  • 12 GB GDDR7 memory at 28 Gbps for high-bandwidth gaming
  • 6144 CUDA cores deliver strong parallel compute performance
  • PCI Express 5.0 x16 interface enables full modern platform throughput
  • Four-display support via two HDMI 2.1b and three DisplayPort 2.1b outputs
  • DirectX 12 Ultimate and OpenGL 4.6 compatibility for latest graphics features

12 GB GDDR7 graphics card for 4K gaming

The ASUS TX Gaming GeForce RTX 5070 OC delivers 12 GB of GDDR7 memory on a 192-bit bus with an effective clock of 28 Gbps. It targets gamers who want high frame rates at 4K resolution using DLSS 4 and ray tracing. The GPU provides 6144 CUDA cores and supports DirectX 12 Ultimate for modern titles. A PCI Express 5.0 x16 link supplies the necessary bandwidth.

Installation fits standard dual-slot PCIe 5.0 slots

Mount the card into a full-length PCI Express 5.0 x16 slot and connect the required power cables from your PSU. Ensure the case offers enough length clearance for the cooler. Driver installation follows the standard NVIDIA GeForce Experience or clean install process. Common issues include forgetting to seat the power connectors fully or running an older motherboard BIOS that limits the link to PCIe 4.0 speeds.

PCIe 5.0 x16 and display outputs define the ceiling

The PCI Express 5.0 x16 interface caps theoretical throughput at the specification maximum for this link width. Display outputs consist of two HDMI 2.1b and three DisplayPort 2.1b ports supporting up to 7680 x 4320 resolution across four monitors. Memory bandwidth is limited by the 192-bit bus and 28 Gbps GDDR7 clocks. No SLI or CrossFireX multi-GPU scaling is available.

Highlights

  • 12 GB GDDR7 memory at 28 Gbps for high-bandwidth gaming
  • 6144 CUDA cores deliver strong parallel compute performance
  • PCI Express 5.0 x16 interface enables full modern platform throughput
  • Four-display support via two HDMI 2.1b and three DisplayPort 2.1b outputs
  • DirectX 12 Ultimate and OpenGL 4.6 compatibility for latest graphics features

Specifications

BrandASUS
SeriesTX
ModelTX-RTX5070-O12G
InterfacePCI Express 5.0
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5070
CUDA Cores6144
Effective Memory Clock28 Gbps
Memory Size12GB
Memory Interface192-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI2 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
CoolerDouble Fans
Recommended PSU Wattage750W
Power Connector1 x 16-Pin
HDCP ReadyYes
Form FactorATX
Max GPU Length329 mm
Card Dimensions (L x H)12.95 x 5.51 x 2.46 inch
Slot Width3.125 Slot

Questions about this item

How can I confirm the 28 Gbps GDDR7 memory is running at full speed after install?

Open GPU-Z or NVIDIA Control Panel and check that the memory clock reports 28 Gbps effective.

What cables or adapters come in the box and what must I supply for a four-monitor setup?

The card provides 2 x HDMI 2.1b and 3 x DisplayPort 2.1b; you supply the matching cables for each monitor you connect.

Which PCI Express slot should I use to get the x16 link this card is built for?

Install it in the primary PCI Express 5.0 x16 slot on your motherboard for full bandwidth.
