Rectangular black desktop NAS with four drive bays and front status LEDs

Buffalo Technology

Buffalo Technology TS3430DN0804 8TB 4-Bay NAS

SKU CH-J7MT-BTTYM MPN TS3430DN0804

A four-bay desktop NAS with 8 TB of pre-installed storage, a quad-core 2.0 GHz processor, 2.5 GbE and 1 GbE ports, plus two USB 3.0 ports for expansion

  • TypeDesktop NAS
  • StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • Ports1 x 1GbE
  • Port RJ-451 x 2.5GbE + 1 x 1GbE
  • Port USB2 x USB3.0
  • HDD Interface4 x SATA (4 x Bay)

Included HDD Capacity 8TB (4 x 2TB)

Option Fully Populated

  • High read/write performance backed by RAID 0, 1, 5, 6, 10 and JBOD
  • 8 TB raw storage from four 2 TB drives included
  • Quad-core 2.0 GHz Annapurna Labs AL-524 processor with 2 GB DDR4
  • Dual LAN ports: 2.5 GbE and 1 GbE for flexible networking
  • Two USB 3.0 ports for external backup or expansion

Purpose-built 4-bay NAS for small teams

The Buffalo TeraStation 3030 TS3430DN0804 ships with four 2 TB drives pre-configured for 8 TB total capacity and runs on an Annapurna Labs AL-524 quad-core processor at 2.0 GHz with 2 GB DDR4 memory. It targets small offices or workgroups that need centralised file storage, backup targets or media serving without a dedicated server room. Buyers who require 10 GbE connectivity, expansion bays beyond four or pre-installed SSD caching should look elsewhere.

Sustained throughput with dual Ethernet

The 2.5 GbE and 1 GbE RJ-45 ports allow link aggregation or separate traffic lanes so RAID 5 or RAID 6 rebuilds and large sequential transfers can continue without saturating a single gigabit link. The AL-524 processor maintains parity calculations during prolonged write workloads while the 33.88 W typical draw keeps heat output modest in a closed cabinet. Environments that demand sustained multi-client 4K video editing streams or database-level IOPS will exceed the platform’s CPU and memory headroom.

Tool-less drive trays and front-panel lock

Each of the four bays uses a tool-less tray that accepts 3.5-inch SATA drives; the included OP-HD2.0N drives slide in and lock with a key-operated front panel. USB 3.0 ports on the rear simplify one-off backups or printer sharing without opening the chassis. Installers who skip the RAID initialisation wizard or mix drive capacities often encounter degraded arrays that require manual recovery via the web UI.

Highlights

  • High read/write performance backed by RAID 0, 1, 5, 6, 10 and JBOD
  • 8 TB raw storage from four 2 TB drives included
  • Quad-core 2.0 GHz Annapurna Labs AL-524 processor with 2 GB DDR4
  • Dual LAN ports: 2.5 GbE and 1 GbE for flexible networking
  • Two USB 3.0 ports for external backup or expansion

Specifications

BrandBUFFALO
SeriesTeraStation 3030
ModelTS3430DN0804
Part NumberTS3430DN0804
TypeDesktop NAS
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ports1 x 1GbE
Port RJ-451 x 2.5GbE + 1 x 1GbE
Port USB2 x USB3.0
HDD Interface4 x SATA (4 x Bay)
Form Factor4-Bay
ProcessorAnnapurna Labs Alpine Processor AL-524 2.0GHz Quad-core
Installed Memory2GB DDR4
Included HDD Capacity8TB (4 x 2TB)
RAIDRAID 0, 1, 5, 6, 10, and JBOD
Drive CompatibilityOP-HD2.0N
Supported ProtocolsTCP/IP
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Power Consumption33.88W
Temperature0°C - 40 °C
Humidity10-80% Non-condensing
UsageHigh read/write performance with RAID
Dimensions9.1 x 6.7 x 8.5 in
Weight13.7 lbs.
Package ContentsTeraStation, Quick Setup Guide, 5e Ethernet Cable, AC Cable, Front Panel Key, and Warranty Statement
Shipping weight7.71 kg
Package size363 × 358 × 310 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power does the TS3430DN0804 draw when the four 2 TB drives are active?

The unit consumes 33.88 W under load with the included drives installed.

Do I need to buy any drives or memory modules before the TS3430DN0804 will boot?

No, four 2 TB SATA drives and 2 GB of DDR4 are already installed and configured.

Can I connect the TS3430DN0804 to a switch that only has 1 GbE ports?

Yes, the 2.5 GbE and 1 GbE RJ-45 ports both negotiate down to 1 GbE automatically.
