Black flat ribbon cable 200mm long with 90 degree right-angle connector for vertical GPU mount

Corn Electronics

Corn Electronics PCIe 5.0 Riser Cable 200mm 90 Degree Right Angle Black

SKU CH-6034-VNV5S

PCIe 5.0 x16 riser cable with 90-degree right-angle connector for vertical GPU mounting at 200mm length

Length 200mm

  • 150mm
  • 200mm

Struck-through versions exist but are not stocked here.

Color Black

  • PCIe 5.0 x16 bandwidth up to 64 GB/s with compatible hardware
  • Tested throughput reaches ~50 GB/s for high-speed GPU data
  • 78 W power delivery via 10 dedicated 12 V pins on 40-pin connector
  • 90° right-angle design with 200 mm length fits vertical GPU mounting
  • Adjustable screw-hole spacing 97–128 mm matches common case brackets

PCIe 5.0 Riser Cable for Vertical GPU Mount

This 200mm right-angle cable connects a graphics card to a motherboard slot for vertical mounting. It supports PCIe 5.0, 4.0 and 3.0 signalling and is built with 30AWG silver-plated copper conductors. The 90-degree connector orientation suits cases designed for upright card installation.

Double-Grounded Shielding and 78W Power Delivery

Each differential pair is individually foil-wrapped and double grounded to reduce electromagnetic interference at high speeds. The 40-pin connector allocates ten pins to 12V for up to 78W and six pins to 3.3V, providing stable power without extra adapters. Adjustable screw holes from 97mm to 128mm match common case mounting patterns.

CPU, Motherboard and Slot Requirements for Full

Achieving the rated 64GB/s peak bandwidth requires an Intel 13th Gen or AMD Ryzen 8700-series processor, a Z790 or newer motherboard, and a direct CPU-attached PCIe 5.0 x16 slot. The graphics card must be a GeForce RTX 50 series or Radeon RX 9000 series model. Systems lacking these components will operate at lower link speeds.

Highlights

  • PCIe 5.0 x16 bandwidth up to 64 GB/s with compatible hardware
  • Tested throughput reaches ~50 GB/s for high-speed GPU data
  • 78 W power delivery via 10 dedicated 12 V pins on 40-pin connector
  • 90° right-angle design with 200 mm length fits vertical GPU mounting
  • Adjustable screw-hole spacing 97–128 mm matches common case brackets

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 40-pin connector and 30AWG silver-plated copper need periodic re-seating or replacement?

The cable is a passive assembly with no moving contacts; the 40-pin connector and 30AWG silver-plated copper conductors are rated for the life of the build and do not require scheduled maintenance.

What is the maximum sustained bandwidth the riser can deliver before signal integrity limits performance?

The riser is tested at ~50 GB/s with PCIe 5.0 x16 hardware; the theoretical ceiling is 64 GB/s, so sustained loads will hit the 50 GB/s measured figure first.

How much heat does the cable generate when delivering 78 W continuously?

The 30AWG silver-plated copper and double-grounded foil shielding keep resistive loss low; the cable runs warm but stays within normal operating temperature without active cooling.
