Silver 1U rack server front with eight 2.5-inch drive bays and bezel

DELL

DELL PowerEdge R650xs 1U Rack Server 2x Xeon Gold 5317 3.0GHz 12-Core 128GB DDR4 8x 960GB SSD H745 57412

SKU CH-2ZB3-0HDN7

A 1U rack server with dual Xeon Gold 5317 3.0 GHz 12-core CPUs, 128 GB DDR4, eight 960 GB SATA SSDs on an H745 controller, dual 10 GbE SFP+ networking.

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • AI Features8 x 960GB SATA SSD
  • CPU TypeIntel Xeon
  • CPU Speed16
  • Dual Xeon Gold 5317 CPUs provide 12 cores each at 3.0 GHz base
  • 128 GB DDR4-2933 ECC memory supports large virtualization workloads
  • PERC H745 RAID controller with 4 GB NV cache enables RAID 0/1/5/6/10/50/60
  • Eight 960 GB SATA SSDs deliver high-capacity flash storage
  • iDRAC9 Enterprise plus dual 1400 W PSUs ensure remote management and power redundancy

Compact 1U Rack Server

The Dell PowerEdge R650xs is a 1U rack server built for dense data centre deployments. It ships with two Intel Xeon Gold 5317 processors running at 3.0GHz with a 3.6GHz turbo frequency. Each CPU provides twelve cores for a total of twenty-four cores. The system includes 128GB of DDR4 2933MHz registered ECC memory across eight DIMM slots.

Virtualisation and Dense Compute

This configuration suits teams running virtualisation clusters, cloud infrastructure or high-performance analytics where rack space is at a premium. The eight-bay 2.5-inch chassis supports SATA, SAS and NVMe drives for flexible storage tuning. Buyers who need GPU acceleration for AI training or larger memory footprints beyond 1TB should evaluate other platforms.

Sustained Load with Redundant Power

Dual 1400 Watt platinum power supplies deliver redundant hot-swap power for continuous operation. The PERC H745 controller with 4GB NV cache and battery backs RAID 0, 1, 5, 6, 10, 50 and 60 during extended write workloads. iDRAC9 Enterprise enables remote monitoring and firmware updates without physical access.

Highlights

  • Dual Xeon Gold 5317 CPUs provide 12 cores each at 3.0 GHz base
  • 128 GB DDR4-2933 ECC memory supports large virtualization workloads
  • PERC H745 RAID controller with 4 GB NV cache enables RAID 0/1/5/6/10/50/60
  • Eight 960 GB SATA SSDs deliver high-capacity flash storage
  • iDRAC9 Enterprise plus dual 1400 W PSUs ensure remote management and power redundancy

Specifications

BrandDELL
SeriesPowerEdge R650xs
ModelR650xs
Part Number3.00 GHz
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
AI Features8 x 960GB SATA SSD
CPU TypeIntel Xeon
CPU Speed16
CPU SocketLGA 4189
Number of CPU Cores12-Core Processor
# of Processors InstalledGold 5317
MAX Processors2
Chipset0
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity1TB
Storage ControllerDell Perc H745 Controller
HDD InterfaceSATA
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell EMC 15G Broadcom 57412 Dual Port 10GbE SFP+ OCP 3.0 Network Card
LAN Ports2 x Ports
Expansion Slots0
Management PortRJ 45
Operating SystemNo
Features8 x 2.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What DDR4 memory speed must my existing DIMMs run at to match the installed 2933MHz modules?

The server ships with 128GB of DDR4 2933MHz registered ECC memory across eight 16GB DIMMs; any added modules should be 2933MHz DDR4 RDIMMs for matched performance.

Can the PERC H745 controller manage my current 2.5" SATA SSDs in the same RAID sets as the new 960GB drives?

Yes, the H745 supports RAID 0, 1, 5, 6, 10, 50 and 60 on SATA 6Gb/s 2.5" drives, so existing SATA SSDs can join the same virtual disks as the eight 960GB units.

How do I confirm the iDRAC9 Enterprise remote management is active after the server powers on?

Connect to the dedicated iDRAC network port, log in with the default credentials shown on the front-panel LCD, and verify the dashboard reports both Xeon Gold 5317 CPUs, 128GB memory and all eight 960GB SSDs as healthy.
