Black 2U rack server chassis with eight 2.5 inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730 2U rack server E5-2609 v3 1.9GHz 16GB DDR4 2x 300GB SAS H730

SKU CH-H0AJ-MCX0Q

2U rack server with Xeon E5-2609 v3 six-core 1.9GHz CPU, 16GB DDR4, two 300GB 15K SAS drives and H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 16GB

HDD 2 x 300GB

  • 2U rack form factor fits dense data-centre deployments
  • Single Intel Xeon E5-2609 v3 six-core 1.9GHz processor handles core workloads
  • 16GB DDR4 memory with 24 DIMM slots for future expansion
  • Dual 300GB 15K SAS drives on H730 RAID controller deliver protected storage
  • Redundant 750W hot-swap power supplies maintain uptime

Dell PowerEdge R730 2U rack server

The Dell PowerEdge R730 is a 2U rack server built around a single Intel Xeon E5-2609 v3 six-core processor running at 1.9 GHz. It ships with 16 GB of DDR4 memory installed across 24 total DIMM slots and includes two 300 GB 15K SAS drives managed by a PERC H730 RAID controller. Dual 750 W redundant power supplies and a DVD-ROM drive complete the configuration.

Suited for capacity-focused workloads

This server suits environments that need dense 2.5-inch drive bays and hardware RAID levels 0, 1, 5, 6, 10, 50 and 60 with up to 64 TB of raw capacity. Buyers who need more than one processor installed, more than 16 GB of memory out of the box, or solid-state drives as standard should look at other configurations. The single CPU limits parallel throughput for heavily threaded applications.

Single Xeon E5-2609 v3 processor

The system contains one six-core Xeon E5-2609 v3 at 1.9 GHz and supports a second processor for expanded core count. Memory can scale to 1 536 GB using DDR4 modules up to 2 400 MT/s across 24 slots. Eight hot-plug 2.5-inch bays accept SAS or SATA drives, and seven PCIe 3.0 slots plus a dedicated PERC slot provide expansion. Remote management is handled by iDRAC8 with Lifecycle Controller.

Highlights

  • 2U rack form factor fits dense data-centre deployments
  • Single Intel Xeon E5-2609 v3 six-core 1.9GHz processor handles core workloads
  • 16GB DDR4 memory with 24 DIMM slots for future expansion
  • Dual 300GB 15K SAS drives on H730 RAID controller deliver protected storage
  • Redundant 750W hot-swap power supplies maintain uptime

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity16GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I pick the single E5-2609 v3 or add a second processor?

The server ships with one six-core 1.9 GHz Xeon and supports up to two CPUs; adding a second doubles core count for heavier virtualisation workloads.

What does the 16 GB DDR4 mean for actual workloads?

16 GB of DDR4 fits small databases or a handful of VMs; the board has 24 slots and can scale to 1536 GB when larger DIMMs are installed.

How fast is the 12 Gbps H730 controller with the 6 Gbps SAS drives?

The PERC H730 runs at 12 Gbps but the supplied 300 GB 15 K drives are 6 Gbps SAS, so throughput is capped at the drive link speed.
