Silver 2U rack server with twelve 3.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730XD 2U rack server E5-2630 v3 2.4GHz 64GB DDR4 3x 300GB SAS H730

SKU CH-KTYG-6EQT0

2U rack server with single Xeon E5-2630 v3, 64 GB DDR4, three 300 GB 15K SAS drives and H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 64GB

Struck-through versions exist but are not stocked here.

HDD 3 x 300GB 15K

Struck-through versions exist but are not stocked here.

  • Eight-core Xeon E5-2630 v3 at 2.4GHz handles parallel workloads
  • 64GB DDR4 across 24 DIMM slots supports memory-intensive applications
  • Three 300GB 15K SAS drives deliver fast sequential access
  • H730 1GB 12Gbps RAID controller enables RAID 0/1/5/6/10/50/60
  • Dual 750W redundant supplies keep the 2U chassis running

Dense 2U storage server

The Dell PowerEdge R730XD packs twelve 3.5-inch hot-plug bays into a 2U rack footprint, driven by a single Xeon E5-2630 v3 at 2.4 GHz and 64 GB of DDR4 across 24 DIMM slots. Three 300 GB 15K SAS drives ship installed behind a Perc H730 controller with 1 GB cache. Redundant 750 W supplies and a DVD-ROM complete the baseline configuration.

SAS topology and PCIe 3.0 ceiling

The backplane accepts SAS or SATA drives at 6 Gbps per port; the H730 supports RAID 0, 1, 5, 6, 10, 50 and 60 across all twelve bays, but the controller and backplane do not exceed 12 Gbps aggregate. Six PCIe 3.0 slots plus the dedicated RAID slot provide expansion, yet total lane budget is capped by the C610 chipset and the single-processor installation. Network I/O defaults to four 1 GbE ports on the daughter card; 10 GbE options exist but are not populated.

Slide rails and cable routing

The chassis slides into standard square-hole racks on included rails; allow 26.8 inches of depth behind the front posts. Hot-plug drive carriers latch tool-free, and the H730 cable harness is pre-routed, but the single CPU means twelve memory slots remain empty — populating them later requires matched DDR4 modules and a second processor kit. iDRAC8 Express is active on the dedicated management port; Enterprise features and vFlash media need licence keys applied before remote KVM or virtual media will function.

Highlights

  • Eight-core Xeon E5-2630 v3 at 2.4GHz handles parallel workloads
  • 64GB DDR4 across 24 DIMM slots supports memory-intensive applications
  • Three 300GB 15K SAS drives deliver fast sequential access
  • H730 1GB 12Gbps RAID controller enables RAID 0/1/5/6/10/50/60
  • Dual 750W redundant supplies keep the 2U chassis running

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity64GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the single E5-2630 v3 or add a second processor for my workload?

The server supports up to two processors. One E5-2630 v3 at 2.4 GHz with eight cores is installed; a second matching CPU can be added later to double the core count.

What does the 64 GB DDR4 figure mean for actual memory speed in this system?

The installed 64 GB DDR4 runs at up to 2400 MT/s, but the exact speed depends on the E5-2630 v3 processor capability and the DIMM population across the 24 slots.

How does the H730 12 Gbps RAID controller limit the 300 GB 15K SAS drives in practice?

The H730 controller provides a 12 Gbps SAS link, while the three 300 GB 15K drives operate at 6 Gbps, so the drives set the effective throughput ceiling.
