Black 4U rack server with 24 front drive bays, bezel and rails

DELL

DELL PowerEdge R930 4U rack server 4x Xeon E7-8890 v4 2.2GHz 24C 384GB DDR4 24x 1.8TB SAS H730P

SKU CH-RJXY-PS00Y

A 4U rack server with four 24-core Xeon E7-8890 v4 processors at 2.2 GHz, 384 GB DDR4 ECC memory, a PERC H730P RAID controller supporting RAID 0/1/5/6/10/50/60, and twenty-four 1.8 TB 10K SAS drives

  • Rack Height4U
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011
  • Number of CPU Cores24-Core Processor
  • # of Processors Installed4
  • 96 cores from four Xeon E7-8890 v4 processors handle massive parallel workloads
  • 384 GB DDR4 ECC memory scales to 12 TB for in-memory databases
  • PERC H730P controller supports RAID 0/1/5/6/10/50/60 with 2 GB cache
  • 24 hot-plug 1.8 TB 10K SAS drives deliver high-capacity enterprise storage
  • iDRAC8 Enterprise enables agent-free remote management and lifecycle automation

4U quad-socket server

The Dell PowerEdge R930 packs four Intel Xeon E7-8890 v4 processors at 2.2 GHz with 24 cores each, delivering 96 total cores for heavy enterprise workloads. It ships with 384 GB of DDR4 2400 MHz registered ECC memory across 48 modules and supports expansion to 12 TB via 96 DIMM slots. The system targets databases, virtualization and analytics that demand maximum compute density in a single rack unit.

Redundant platinum power

Four 1100 W 80+ Platinum power supplies provide full redundancy for continuous operation under load. The 4U chassis uses hot-plug fans and a mature RAS platform to manage thermals while sustaining 24 SAS drives and quad-processor throughput. iDRAC8 Enterprise enables remote thermal monitoring and power control without agent software.

Dense storage and I/O

Twenty-four 2.5-inch bays hold the included 1.8 TB 10K SAS drives on a PERC H730P controller with 2 GB cache and battery-backed write-back. The H730P supports RAID 0, 1, 5, 6, 10, 50 and 60 for flexible data protection. A quad-port network daughter card adds two 1 GbE and two 10 Gb SFP+ links, while front-accessible NVMe slots remain available for future ultra-fast storage tiers.

Highlights

  • 96 cores from four Xeon E7-8890 v4 processors handle massive parallel workloads
  • 384 GB DDR4 ECC memory scales to 12 TB for in-memory databases
  • PERC H730P controller supports RAID 0/1/5/6/10/50/60 with 2 GB cache
  • 24 hot-plug 1.8 TB 10K SAS drives deliver high-capacity enterprise storage
  • iDRAC8 Enterprise enables agent-free remote management and lifecycle automation

Specifications

BrandDELL
SeriesPowerEdge R930
Rack Height4U
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011
Number of CPU Cores24-Core Processor
# of Processors Installed4
MAX Processors4
ChipsetIntel C602J
Installed Memory Size384GB
Memory TypeDDR4
Max Memory Capacity12TB
Number of Memory Slots96
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the 24 1.8TB SAS drives and what step is often missed?

Slide each 2.5" drive into the front hot-plug bays until the latch clicks; the step often missed is creating the virtual disks in the PERC H730P BIOS before the OS sees any volume.

What maintenance will the PERC H730P 2GB cache battery need later?

The controller uses a battery-backed cache module; plan to replace the battery pack every 3 to 5 years to keep write-back caching protected during power loss.

What limit appears first when all 96 cores run sustained turbo at 3.4GHz?

The four 1100W Platinum power supplies set the system power envelope; sustained 3.4GHz turbo on all cores will reach that envelope before thermal limits.
