DELL
DELL PowerEdge T430 16SFF Xeon E5-2680v4 256GB DDR4 rack server
A 16-bay 2.5-inch rack server with one 14-core Xeon E5-2680v4 at 2.4 GHz, 256 GB DDR4 ECC memory, PERC H730 SAS controller and dual 1100 W supplies
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.4GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size256GB
- 14-core Xeon E5-2680v4 at 2.4 GHz handles heavy workloads
- 256 GB DDR4 ECC memory supports large datasets
- 16 SFF drive bays allow flexible storage expansion
- PERC H730 SAS controller provides hardware RAID
- iDRAC8 Express enables remote server management
Dell PowerEdge T430 16-bay server
This Dell PowerEdge T430 is a 16-bay rack server built for dense storage workloads. It ships with a single Intel Xeon E5-2680v4 processor running at 2.4GHz with 14 cores and 35MB cache. The system includes 256GB of DDR4 ECC registered memory and a PERC H730 SAS controller. It is sold without drives, allowing custom capacity configuration.
Suits storage-heavy roles not GPU compute
This configuration fits organisations needing maximum 2.5-inch drive density in a 2U footprint for databases, virtualisation hosts or backup targets. The single CPU and integrated graphics limit performance for heavily threaded compute or any workload requiring discrete GPU acceleration. Buyers who need more than 256GB RAM or dual-processor throughput should look at a different chassis.
16 x 2.5-inch drive bays define capacity
The chassis supports up to sixteen 2.5-inch SATA or SAS drives connected to the PERC H730 controller. This bay count is the primary constraint on total raw storage and RAID layout options. No drives are installed, so the final capacity and performance depend entirely on the drives selected during configuration.
Highlights
- 14-core Xeon E5-2680v4 at 2.4 GHz handles heavy workloads
- 256 GB DDR4 ECC memory supports large datasets
- 16 SFF drive bays allow flexible storage expansion
- PERC H730 SAS controller provides hardware RAID
- iDRAC8 Express enables remote server management
Specifications
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.4GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 256GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 384GB |
| Hard Drive (Installed) | 3,84 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Express License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
Does the PERC H730 SAS controller support the SATA drives I already own?
Yes, the PERC H730 SAS controller accepts SATA drives, so existing 2.5" SATA drives can be installed in the 16 drive bays.
Will my existing DDR4 ECC registered modules work with the 256GB already installed?
The system uses DDR4 ECC registered memory and supports up to 384GB total, so compatible modules can fill the remaining capacity.
How do I confirm the iDRAC8 Express remote management is active after setup?
Connect the dedicated iDRAC network port, power on the server, and access the iDRAC web interface using the IP shown on the front LCD panel.
