Small green circuit board with gold edge connector and black chips, 30 by 50 millimetres

Dogfish Technology

Dogfish Technology mSATA 128GB internal SSD

SKU CH-SF67-NEP92

Compact mSATA drive stores 128GB with 3D NAND and sequential speeds up to 450MB/s read and 200MB/s write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactormSATA
  • Capacity128GB
  • Memory Components3D NAND
  • InterfaceMini-SATA (mSATA)

Options 128GB

  • mSATA form factor fits compact notebooks and ultrabooks
  • Sequential read up to 450 MB/s speeds up boot and app load
  • Sequential write up to 200 MB/s handles everyday file saves
  • 3D NAND TLC memory with ECC and bad-block management protects data
  • MTBF of 10000000 hours indicates long-term reliability

Compatibility Check

Before ordering confirm the host has a free mSATA slot supporting SATA III 6 Gb/s operation. The drive measures 30mm wide by 50.88mm deep and sits 1mm high so verify clearance inside the chassis or notebook bay. Operating temperature range is 0°C to 75°C and humidity tolerance reaches 95% non‑condensing.

Controller and Firmware Features

The SM2256KAB controller enables DevSleep ultra low power state and supports SMART monitoring TRIM and NCQ commands. Built‑in ECC with averaging algorithm and bad‑block management provide on‑the‑fly error correction. 3D NAND TLC flash reduces cell‑to‑cell interference for longer endurance rated at 10000000 hours MTBF.

Highlights

  • mSATA form factor fits compact notebooks and ultrabooks
  • Sequential read up to 450 MB/s speeds up boot and app load
  • Sequential write up to 200 MB/s handles everyday file saves
  • 3D NAND TLC memory with ECC and bad-block management protects data
  • MTBF of 10000000 hours indicates long-term reliability

Specifications

BrandTHREE COLOUR DOGFISH
SeriesmSATA-128GB
ModelmSATA-128GB
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactormSATA
Capacity128GB
Memory Components3D NAND
InterfaceMini-SATA (mSATA)
ControllerSM2256KAB
Max Sequential ReadUP TO 450MBps
Max Sequential WriteUP TO 200MBps
MTBF10,000,000 hours
Operating Temperature0°C ~ +75°C
Storage Temperature-40°C ~ +85°C
Operating Humidity0% ~ 95%
Height1mm
Width30mm
Depth50.88mm
Weight20g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the Dogfish mSATA 128GB drive ship with mounting hardware or cloning software, or must I buy them separately?

The drive is supplied as a bare mSATA module only; screws, brackets, cables and migration software are not included and must be sourced separately if your system requires them.

The product page mentions both 450 MB/s and 550 MB/s read speeds — which figure should I expect for this 128GB model?

The detailed specification lists up to 450 MB/s sequential read and up to 200 MB/s sequential write for this capacity; the 550 MB/s figure applies to higher-capacity variants in the same series.

Will I see the advertised 450 MB/s read speed once the SSD is installed in my laptop?

Real-world throughput depends on the host SATA controller, cable quality, file system overhead and thermal conditions; the 450 MB/s figure is a best-case sequential benchmark, not a guaranteed sustained rate in every system.
