Square black metal axial fan housing 180mm wide 90mm deep with wire grille guard

Fans

Fans UF18JC23-HSize CPU cooler 180x180x90mm 230V 0.42A 390 CFM 2850RPM 54dB

SKU CH-DCA7-WZW62 MPN UF18JC23-HSize

Axial CPU cooler measuring 180×180×90 mm moves 390 CFM at 2850 RPM with 54 dB noise on 230 V power

  • High airflow with 390 CFM axial design
  • 2850 RPM speed delivers strong cooling pressure
  • 230 V AC input suits industrial power systems
  • Compact 180 x 180 x 90 mm frame fits tight spaces
  • 54 dB noise level balances performance and acoustics

Industrial axial fan for 230 V equipment cooling

The UF18JC23-HSize is a 180 by 180 by 90 mm axial fan rated for 230 V AC at 0.42 A. It delivers 390 CFM airflow at 2850 RPM with a static pressure of 20 mmH2O and 54 dB noise. Designed for industrial enclosures, UPS units, medical devices and rail-vehicle drive cooling where mains-powered forced convection is required.

Verify mains voltage and mounting clearance before

Confirm the installation site supplies 230 V AC and can accommodate the 180 mm square footprint with 90 mm depth. The fan draws 0.42 A, so the circuit must handle the load. Ensure the 18090 mounting pattern matches the chassis cut-out and that the 54 dB operating noise is acceptable for the intended environment.

No bundled accessories or software included

The unit ships as a standalone fan without cables, guards, filters or control software. Integrators must supply their own wiring, mounting hardware and any speed-control or monitoring solution required by the application.

Highlights

  • High airflow with 390 CFM axial design
  • 2850 RPM speed delivers strong cooling pressure
  • 230 V AC input suits industrial power systems
  • Compact 180 x 180 x 90 mm frame fits tight spaces
  • 54 dB noise level balances performance and acoustics

Specifications

No published specifications for this item yet.

Questions about this item

Does the UF18JC23-HSize ship with mounting brackets or a power cord, or must I buy them separately?

The supplied data lists only the fan unit itself; no brackets, screws or IEC cable are mentioned, so plan to source mounting hardware and a suitable 230 V power lead separately.

The spec sheet shows a single 230 V 0.42 A model — are there alternative voltage or speed versions I should consider?

Only the 230 V, 2850 RPM, 390 CFM variant appears in the data; no other voltage, current or speed options are documented for this MPN.

With 54 dB noise and 20 mmH₂O pressure, how will this cooler perform inside a typical workstation chassis?

At 54 dB the fan is clearly audible, while 20 mmH₂O static pressure means it can push air through dense heatsinks or restricted grilles, making it suited to industrial or server enclosures rather than quiet desktop builds.
