Light gray Mini-ITX tower with sliding textile wrap, top-mounted 180 mm fan, compact pillar shape

Fractal Design

Fractal Design FD-C-MOD1N-01 Light Gray Mini-ITX PC case

SKU CH-9VMQ-QNFPX MPN FD-C-MOD1N-01

A compact 20L Mini-ITX chassis with sliding textile panels, included 180 mm top fan, PCIe 4.0 riser, and room for 325 mm GPUs plus 280 mm side radiators

  • TypeSmall Form Factor
  • ColorLight Gray
  • Case MaterialSteel, Plastic, Cloth
  • With Power SupplyNo
  • Power Supply MountedTop
  • Motherboard CompatibilityMini ITX

Options White

  • Compact 20 L footprint fits Mini-ITX builds
  • Sliding textile enclosure gives quick hardware access
  • 180 mm Dynamic X2 PWM fan cools quietly out of the box
  • PCIe 4.0 riser cable included for flexible GPU mounting
  • Supports radiators up to 280 mm and GPUs up to 325 mm

Mini-ITX pillar case with textile enclosure

The Fractal Design Mood is a 20-litre small-form-factor chassis built for Mini-ITX motherboards. A sliding cloth wrap replaces conventional side panels, giving quick access to components while keeping a low-profile look. The steel-and-plastic frame ships without a power supply, leaving the choice of SFX unit to the builder. It suits compact workstation or living-room builds that value tidy aesthetics.

PCIe 4.0 riser limits GPU placement to two slots

The included PCIe 4.0 riser cable connects the graphics card horizontally, so only two expansion slots are usable. Maximum graphics-card length is 325 mm, and the riser’s 4.0 signalling sets the practical bandwidth ceiling for modern GPUs. Front I/O provides one USB 3.2 Gen 2x2 Type-C port, two USB 3.0 Type-A ports and a single audio jack. No other internal interfaces are exposed.

180 mm top fan and side radiator support define

A pre-installed 180 mm PWM fan exhausts through the top, while the side panel accepts two 140 mm or 120 mm fans and radiators up to 280 mm (148 mm max width). Using a 280 mm or 240 mm radiator removes the single 3.5-inch drive bay. CPU cooler height is capped at 110 mm and power-supply length at 130 mm. These dimensions set the thermal envelope for any build.

Highlights

  • Compact 20 L footprint fits Mini-ITX builds
  • Sliding textile enclosure gives quick hardware access
  • 180 mm Dynamic X2 PWM fan cools quietly out of the box
  • PCIe 4.0 riser cable included for flexible GPU mounting
  • Supports radiators up to 280 mm and GPUs up to 325 mm

Specifications

BrandFractal Design
SeriesMood
ModelFD-C-MOD1N-01
TypeSmall Form Factor
ColorLight Gray
Case MaterialSteel, Plastic, Cloth
With Power SupplyNo
Power Supply MountedTop
Motherboard CompatibilityMini ITX
Side Panelwithout Side Window
LEDNo
Dust FiltersRear magnetic filter mesh
Internal 3.5" Drive Bays1 (included)
Internal 2.5" Drive Bays2 (included)
Expansion Slots2
Front Ports1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.0 Type-A, 1 x Audio
Fan OptionsTotal fan mounts: 3, 1x 180 mm, 2x 140/120 mm
Top: 1x 180 mm (1x Dynamic X2 180 mm PWM included)
Side: 2x 140 mm or 2x 120 mm
Pre-installed FansTop - 1 x 180mm
Radiator OptionsSide: 280/240/140/120 mm side mounted (148 mm max width) (no 3.5" drive with 280/240)
Max GPU Length325 mm
Max CPU Cooler Height110 mm
Max PSU Length130 mm
Dimensions8.35" x 8.35" x 17.83"
Weight10.14 lbs.
Features• Install your choice of high-performing GPU up to 325 mm in length, in a space-saving pillar 20 L case
• Enjoy a sleek breathable subtly textured double layered fabric exterior with a perforated back and top mesh panel for targeted ventilation.
• Find your build’s ideal cooling balance with an included 180mm fan in a chimney cooling configuration with options for an additional two 140mm fans.
• Flexible cooling options allow for up to a 280mm Aio or a 110mm Tower cooler.
• Front-facing I/O featuring two USB 3.0 5Gbps type A ports, one USB Type-C 20Gbps (3.2 gen 2x2) and one combo ja
Package ContentMood Case
Accessory box
Manual
Shipping weight6.12 kg
Package size559 × 305 × 305 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will a full-length graphics card fit inside this 20 L chassis?

The case accepts GPUs up to 325 mm long, which covers most dual- and triple-slot models on the market.

Can I run a 280 mm liquid-cooling radiator and still keep a 3.5" hard drive?

A 280 mm radiator mounts on the side, but the 3.5" bay must be removed when a 280 mm or 240 mm radiator is installed.

What power-supply length limit applies with the PSU mounted at the top?

The top-mounted PSU bracket supports units up to 130 mm deep, so choose an SFX or short ATX model accordingly.
