Fractal Design
Fractal Design Terra Jade FD-C-TER1N-03 Mini-ITX PC case
A 10.4 L Mini-ITX case with an anodized aluminum front, solid walnut panel, PCIe 4.0 riser and room for 322 mm GPUs
- TypeSmall Form Factor
- ColorJade
- Case MaterialAluminum / Steel
- With Power SupplyNo
- Power SupplySFX/SFX-L
- Power Supply MountedRear
- Space-saving 10.4 L footprint fits powerful Mini-ITX builds
- Solid walnut panel adds premium warmth to the aluminium exterior
- Movable interior wall gives 30 mm extra room for GPU or cooler
- PCIe 4.0 riser cable included for full-speed graphics connection
- Two 2.5" drive bays provide fast internal storage capacity
Jade Mini-ITX case for compact builds
The Fractal Design Terra Jade is a 10.4 L small form factor enclosure built from anodized aluminium and steel with a solid walnut accent panel. It accepts Mini-ITX motherboards and uses an SFX or SFX-L power supply mounted at the rear. A PCIe 4.0 riser cable is included so the graphics card sits parallel to the motherboard.
Check GPU height thickness and CPU cooler clearance
In the maximum GPU configuration the case allows cards up to 322 mm long, 131 to 145 mm tall and 62 to 72 mm thick depending on the chosen height. That same layout limits the CPU cooler to 48 mm. Switching to the maximum CPU configuration raises the cooler limit to 77 mm but reduces the expansion slots from three to two. Verify which layout matches your parts before ordering.
Single 120 mm mount handles sustained loads
One 120 mm fan mount sits at the bottom and a side radiator bracket supports a 120 mm unit up to 121 mm wide when the GPU is 200 mm or shorter and no 2.5 inch drives are installed. No fans are pre-installed so you choose the airflow profile. The movable interior wall provides 30 mm of adjustment to balance GPU length against cooler height during extended workloads.
Highlights
- Space-saving 10.4 L footprint fits powerful Mini-ITX builds
- Solid walnut panel adds premium warmth to the aluminium exterior
- Movable interior wall gives 30 mm extra room for GPU or cooler
- PCIe 4.0 riser cable included for full-speed graphics connection
- Two 2.5" drive bays provide fast internal storage capacity
Specifications
| Brand | Fractal Design |
|---|---|
| Series | Terra |
| Model | FD-C-TER1N-03 |
| Type | Small Form Factor |
| Color | Jade |
| Case Material | Aluminum / Steel |
| With Power Supply | No |
| Power Supply | SFX/SFX-L |
| Power Supply Mounted | Rear |
| Motherboard Compatibility | Mini ITX |
| Side Panel | without Side Window |
| Internal 2.5" Drive Bays | 2 (included) |
| Expansion Slots | 3 in Max GPU Config, 2 in Max CPU Config |
| Front Ports | 1 x USB 3.2 Gen 2x2 Type-C, 1 x USB 3.0 Type-A, |
| Fan Options | Total fan mounts: 1x 120 mm Bottom: 1x 120 mm |
| Pre-installed Fans | No Fan Installed |
| Radiator Options | Side: 120 mm (Max 121 mm wide w/ GPU up to 200 mm long and no 2.5" drives) |
| Max GPU Length | 322 mm Max GPU Height: 131 - 145 mm depending on thickness Max GPU Thickness: 62 - 72 mm depending on height (Max GPU config) |
| Max CPU Cooler Height | 77 mm in Max CPU config, 48 mm in Max GPU config |
| Max PSU Length | 130 mm |
| Dimensions | 13.50" x 6.02" x 8.58" |
| Weight | 6.83 lbs. |
| Features | • Install your choice of high-performing GPU up to 322 mm in length, in a space-saving 10.4 L case • Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut • Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front • Find your build’s ideal balance with 30 mm of internal flexibility provided by a stepless, slidable central wall • Front-facing I/O featuring an aluminum power button and two USB ports including one USB Type-C 20Gbps • Get a head start on your build with the included PCIe 4.0 Riser cable • Store up to two |
| Package Content | Terra Case Accessory box Manual |
| Shipping weight | 4.31 kg |
| Package size | 403 × 292 × 219 mm |
Other versions of this model
2 more in the same range
Same family, different memory, cooler or clock — compare before you commit.
Fractal Design
Fractal Design FD-C-TER1N-02 Terra Silver Mini-ITX PC Case
- Small Form Factor
- Silver
$199.99
0.00256493BTC
In stockQuestions about this item
Will a dual-slot graphics card longer than 322 mm fit inside this case?
No, the maximum supported GPU length is 322 mm. Cards exceeding that dimension will not install.
What CPU cooler height can I use if I also install a full-length graphics card?
In the maximum GPU configuration the cooler clearance is 48 mm, so only low-profile coolers will fit.
Does the case include any pre-installed fans or must I supply my own?
No fans are pre-installed; the chassis provides one 120 mm bottom mount for you to add a fan.
