Full-height dual-slot graphics card with silver cooler and four DisplayPort plus one DVI output

Fujitsu

Fujitsu 5.1 Nvidia Quadro P5000 16GB GDDR5X workstation graphics card

SKU CH-DSP8-69R57 MPN 5.1

A workstation graphics card with 16 GB GDDR5X memory, 2560 CUDA cores, and four DisplayPort 1.4 plus DVI-D outputs for up to four displays

  • Memory TypeGDDR5X
  • 16 GB GDDR5X memory handles large datasets and complex models
  • 2560 CUDA cores accelerate rendering and compute workloads
  • 288 GB/s bandwidth feeds the GPU for smooth 4K and 8K output
  • Four DisplayPort 1.4 plus DVI-D DL drive up to four displays
  • 180 W power draw fits standard workstation power supplies

Workstation GPU for professional visualisation

The Fujitsu Nvidia Quadro P5000 delivers 16 GB of GDDR5X memory on a 256-bit bus with 2560 CUDA cores. It targets engineers, designers and researchers who need certified drivers for CAD, simulation and content-creation applications. The PCI Express 3.0 x16 interface fits standard workstation motherboards.

Dual-slot card with 180 W power draw

The board measures 4.4” high by 10.5” long and occupies two full-height slots with an active thermal solution. A 180 W maximum power draw means the host power supply must provide sufficient PCIe auxiliary connectors. Four DisplayPort 1.4 outputs and one dual-link DVI-D connector drive up to four simultaneous displays without additional adapters.

Multi-display support up to 8K resolution

Each DisplayPort 1.4 handles 7680 x 4320 at 30 Hz while the DVI-D dual-link reaches 2560 x 1600 at 60 Hz. Multi-Stream Transport lets a single port drive multiple monitors in a daisy-chain. Supported APIs include DirectX 12.05, OpenGL 4.54, Vulkan 1.04, CUDA, DirectCompute and OpenCL for compute workloads.

Highlights

  • 16 GB GDDR5X memory handles large datasets and complex models
  • 2560 CUDA cores accelerate rendering and compute workloads
  • 288 GB/s bandwidth feeds the GPU for smooth 4K and 8K output
  • Four DisplayPort 1.4 plus DVI-D DL drive up to four displays
  • 180 W power draw fits standard workstation power supplies

Specifications

Memory TypeGDDR5X

Questions about this item

How much power does the Quadro P5000 draw under sustained load?

The card has a maximum power consumption of 180 W and uses an active thermal solution to manage heat during continuous operation.

What is the noise and heat profile when the card runs all day?

An active cooler handles the 180 W thermal design power, keeping the dual-slot, full-height card within operating limits during extended workloads.

Which power connectors must my supply provide for this card to work?

The card installs in a PCI Express 3.0 x16 slot and requires supplementary PCIe power connectors to reach its 180 W maximum draw.
