Green rectangular mATX motherboard with silver heatsinks and four black DDR5 slots

GIGABYTE

GIGABYTE A620M GAMING X AX (Rev. 1.1) AMD motherboard

SKU CH-2D5J-F3NJJ

Micro-ATX AM5 board with DDR5 support up to 192 GB, PCIe 4.0 graphics and M.2 slots, Wi-Fi 6E, 1 GbE LAN and tool-free EZ-Latch installation

  • CPU Socket TypeAM5
  • ChipsetAMD A620
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardDDR5 5200
  • Maximum Memory Supported192GB
  • Channel SupportedDual Channel
  • Supports Ryzen 7000, 8000 and 9000 series processors on AM5 socket
  • Four DDR5 slots accept up to 192 GB with EXPO and XMP profiles
  • 8+2+1 phase digital VRM with thermal guard keeps power delivery stable
  • PCIe 4.0 x16 and M.2 slots feature screwless EZ-Latch quick release
  • Wi-Fi 6E, BLUETOOTH 5.2 and 1 GbE LAN provide flexible connectivity

AM5 Socket for Ryzen 7000 8000 9000 Series

This motherboard accepts AMD Ryzen 7000 8000 9000 Series processors on the AM5 socket. Four 288-pin slots support DDR5 memory up to 192 GB in dual-channel mode. AMD EXPO and Intel XMP 3.0 profiles are both supported for memory tuning. The 8+2+1 phase digital VRM delivers stable power for mainstream CPUs.

PCIe 4.0 Limits with Ryzen 8000 Processors

The primary PCIe x16 slot runs at PCIe 4.0 x16 with Ryzen 7000 CPUs but drops to x8 with Ryzen 8000 Phoenix 1 and Phoenix 2 processors. A single M.2 connector wired to the CPU supports PCIe 4.0 x4 SSDs for Ryzen 7000 and compatible Ryzen 8000 chips. The second PCIe slot is limited to PCIe 3.0 x1. Four SATA 6 Gb/s ports and NVMe RAID 0 1 10 round out storage options.

EZ-Latch Plus Simplifies GPU and M.2 Installation

PCIe 4.0 x16 and M.2 connectors feature screwless quick-release latches so graphics cards and SSDs install without tools. Q-Flash Plus allows BIOS updates without a CPU or memory installed. Wi-Fi 6E and BLUETOOTH 5.2 share the 1 GbE LAN port for networking. Smart Fan 6 provides header-based cooling control for the VRM heatsink and M.2 thermal guard.

Highlights

  • Supports Ryzen 7000, 8000 and 9000 series processors on AM5 socket
  • Four DDR5 slots accept up to 192 GB with EXPO and XMP profiles
  • 8+2+1 phase digital VRM with thermal guard keeps power delivery stable
  • PCIe 4.0 x16 and M.2 slots feature screwless EZ-Latch quick release
  • Wi-Fi 6E, BLUETOOTH 5.2 and 1 GbE LAN provide flexible connectivity

Specifications

BrandGIGABYTE
ModelA620M GAMING X AX (Rev. 1.1)
CPU Socket TypeAM5
ChipsetAMD A620
Number of Memory Slots4x288pin (DDR5)
Memory StandardDDR5 5200
Maximum Memory Supported192GB
Channel SupportedDual Channel
Memory Performance ProfileIntel XMP 3.0 / AMD EXPO
Memory FeatureDual channel memory architecture
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
PCI Express 4.0 x161 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
AMD Ryzen 7000 Series Processors support PCIe 4.0 x16 mode
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
PCI Express x11 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2580 SSDs:
- AMD Ryzen 7000 Series Processors support PCIe 4.0 x4/x2 SSDs
- AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
- AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
SATA RAIDRAID 0, RAID 1, and RAID 10 support for SATA storage devices
Additional RAID ControllerRAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
Audio Channels7.1 Channels
Max LAN Speed1Gbps
Wireless LANWi-Fi 802.11 ax
BluetoothBLUETOOTH 5.2
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x USB Type-C port, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 2 Type-A port (red)
2 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x HDMI port
1 x DisplayPort
1 x Q-Flash Plus button
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x CPU fan header
2 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x Clear CMOS jumper
Form FactorMicro ATX
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
Windows 11Support for Windows 11 64-bit
Support for Windows 10 64-bit
FeaturesSupport for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus

Questions about this item

Which DDR5 memory capacity should I choose for the four 288-pin slots?

The board supports up to 192 GB across four DDR5 DIMMs running in dual-channel mode at 5200 MT/s with AMD EXPO or Intel XMP 3.0 profiles.

What does the PCIe 4.0 x16 slot deliver with a Ryzen 7000 series CPU installed?

A Ryzen 7000 processor enables full PCIe 4.0 x16 bandwidth on the primary slot, while Ryzen 8000 Phoenix 1 CPUs run the same slot at x8 speed.

How fast is the onboard Wi-Fi 6E and BLUETOOTH 5.2 connection in practice?

Wi-Fi 6E (802.11 ax) and Bluetooth 5.2 provide modern wireless throughput, while the wired Realtek LAN caps at 1 Gbps for stable networking.
