Black ATX motherboard with silver heatsinks, four DDR5 slots and multiple M.2 shields

GIGABYTE

GIGABYTE B760 GAMING X AX Intel motherboard

SKU CH-B39Y-31GDC

ATX board for 12th and 13th Gen Intel CPUs with four DDR5 slots up to 128 GB, three PCIe 4.0 M.2 sockets, 2.5 GbE LAN and WiFi 6E

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel Core 13th Gen (LGA 1700)
  • ChipsetIntel B760
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardSupport for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.
  • Maximum Memory Supported128GB
  • Supports 13th and 12th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR5 with four slots and speeds up to 7600 MT/s overclocked
  • Hybrid 8+1+1 phase digital VRM for stable power delivery
  • PCIe 4.0 x16 slot plus three M.2 connectors for fast storage
  • 5GbE LAN and WiFi 6E for high-speed networking

Intel LGA 1700 ATX Motherboard

The GIGABYTE B760 GAMING X AX is an ATX motherboard built for Intel Core 12th and 13th generation processors using the LGA 1700 socket. It targets builders who want a full-size board with modern connectivity and DDR5 memory support. The Intel B760 chipset provides a stable platform for gaming and productivity systems.

Four DDR5 Slots Up to 7600 MT/s

Memory support is the specification that defines this board. Four 288-pin slots run dual-channel DDR5 at speeds from 4800 to 7600 MT/s when overclocked, with a maximum capacity of 128 GB. This range lets you match memory kits to your budget and performance goals without changing the motherboard.

Q-Flash Plus and PCIe EZ-Latch

Q-Flash Plus updates the BIOS without a CPU, memory or graphics card installed, so you can prepare the board for newer processors before the first boot. PCIe EZ-Latch releases the graphics card and M.2 shields with a single press, making hardware swaps faster during builds or upgrades.

Highlights

  • Supports 13th and 12th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR5 with four slots and speeds up to 7600 MT/s overclocked
  • Hybrid 8+1+1 phase digital VRM for stable power delivery
  • PCIe 4.0 x16 slot plus three M.2 connectors for fast storage
  • 5GbE LAN and WiFi 6E for high-speed networking

Specifications

BrandGIGABYTE
ModelB760 GAMING X AX
CPU Socket TypeLGA 1700
CPU TypeIntel Core 13th Gen (LGA 1700)
ChipsetIntel B760
Number of Memory Slots4x288pin (DDR5)
Memory StandardSupport for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0
Serial ATA (SATA)4 x SATA 6Gb/s
M.2CPU:
1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2M_SB)
Max LAN Speed2.5Gbps
Wireless LANWiFi 6E
Form FactorATX
FeaturesQ-Flash Plus
PCIe EZ-Latch

Questions about this item

What does DDR5 7600(O.C.) mean for actual memory speed on this board?

The board supports DDR5 modules up to 7600 MT/s when overclocked, with standard JEDEC speeds at 4800 MT/s; actual speed depends on the CPU memory controller and the XMP/EXPO profile on the modules.

Which PCIe generation does the primary M.2 slot use and what bandwidth does it provide?

The CPU-connected M.2 slot runs at PCIe 4.0 x4, giving up to 8 GB/s theoretical bandwidth for a compatible SSD.

What size DDR5 DIMMs and how many can I install in the four slots?

The board has four 288-pin DDR5 slots supporting up to 128 GB total in dual-channel mode.
