Green Micro-ATX motherboard with silver heatsinks and four black DDR5 slots

GIGABYTE

GIGABYTE B760M C V3 Intel motherboard

SKU CH-1WCH-YYV3D

Micro-ATX board for Intel Core 12, 13, 14 processors with DDR5 memory up to 256 GB, PCIe 5.0 x16 slot, four SATA ports, three M.2 sockets, Wi-Fi 6 and Bluetooth 5.3

  • CPU Socket TypeLGA 1700
  • ChipsetIntel B760
  • Number of Memory Slots4x288pin (DDR5)
  • Maximum Memory Supported256GB
  • Channel SupportedDual Channel
  • ECC SupportedYes
  • Supports 12th, 13th and 14th Gen Intel Core CPUs via LGA 1700
  • Hybrid 6+1+1 phase digital VRM for stable power delivery
  • Four DDR5 DIMM slots with dual-channel ECC support up to 256 GB
  • Three PCIe 4.0 M.2 slots plus four SATA 6 Gb/s with RAID 0, 1, 5, 10
  • Wi-Fi 6 and BLUETOOTH 5.3 with EZ-Plug antenna plus 1 GbE LAN

GIGABYTE B760M C V3 Overview

This micro-ATX motherboard uses the Intel B760 chipset and an LGA 1700 socket to support 12th, 13th and 14th generation Core processors. It provides four DDR5 DIMM slots for up to 256 GB of dual-channel memory with ECC capability.

Who This Suits

Builders who want a compact board with Wi-Fi 6, BLUETOOTH 5.3 and a PCIe 5.0 x16 slot for a graphics card or NVMe SSD will find the feature set complete. Users requiring faster Ethernet or more than four SATA ports should look at something else.

Deciding Specification

The single PCIe 5.0 x16 slot can operate only as a graphics card slot or as an M.2 NVMe slot, not both simultaneously, so confirm which device you intend to install before purchase.

Highlights

  • Supports 12th, 13th and 14th Gen Intel Core CPUs via LGA 1700
  • Hybrid 6+1+1 phase digital VRM for stable power delivery
  • Four DDR5 DIMM slots with dual-channel ECC support up to 256 GB
  • Three PCIe 4.0 M.2 slots plus four SATA 6 Gb/s with RAID 0, 1, 5, 10
  • Wi-Fi 6 and BLUETOOTH 5.3 with EZ-Plug antenna plus 1 GbE LAN

Specifications

BrandGIGABYTE
ModelB760M C V3
CPU Socket TypeLGA 1700
ChipsetIntel B760
Number of Memory Slots4x288pin (DDR5)
Maximum Memory Supported256GB
Channel SupportedDual Channel
ECC SupportedYes
Buffer SupportedUn-buffered
Memory FeatureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
PCI Express 5.0 x161 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
PCI Express 3.0 x161 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1(PCIEX1_1/2)
Serial ATA (SATA)4 x SATA 6Gb/s
M.2CPU:
- 1 x M.2 connector (Socket 3, M key, type 22110/ 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2P_SB)
- 2 x M.2 connectors (Socket 3, M key, type 2280 PCIe 3.0 x1 SSD support)(M2X_SB, M2Y_SB)
SATA RAIDRAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Audio ChipsetRealtek ALC897
Audio Channels7.1 Channels
Max LAN Speed1Gbps
Wireless LANWi-Fi 802.11 ax
BluetoothBLUETOOTH 5.3
Back I/O Ports1 x PS/2 keyboard/mouse port
2 x antenna connectors (1T1R)
1 x HDMI port (Note)
1 x DisplayPort (Note)
1 x USB 3.2 Gen 2 Type-A port (red)
1 x USB Type-C port, with USB 3.2 Gen 2x2 support
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
3 x USB 2.0/1.1 headers
Other Connectors1 x CPU fan header
3 x system fan headers
3 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x speaker header
2 x Thunderbolt add-in card connectors
1 x Q-Flash Plus button
1 x reset button
1 x reset jumper
1 x Clear CMOS jumper
1 x chassis intrusion header
BIOS Feature1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form FactorMicro ATX
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
FeaturesSupport for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup

Questions about this item

Does the board come with Wi-Fi antennas or do I need to buy them separately?

The WIFI EZ-Plug design includes antennas in the box for the integrated Wi-Fi 6 and Bluetooth 5.3 module.

Which M.2 slot should I use for the fastest NVMe drive?

The CPU-linked M2A_CPU slot supports PCIe 4.0 x4 and accepts 2280 or 22110 drives for maximum throughput.

What does the PCIe 5.0 x16 slot actually deliver for a graphics card?

The primary PCIEX16 slot runs at PCIe 5.0 x16 electrically, giving a modern GPU the full bandwidth the platform provides.
