Green Micro ATX motherboard with silver CPU socket, four black DIMM slots, PCIe x16 slot, rear I/O shield, SATA ports, matte black PCB

GIGABYTE

GIGABYTE GA-B460M DS3H V2 Intel motherboard

SKU CH-YQJH-9MQKK

Micro-ATX Intel B460 board with LGA1200 socket supporting up to 128 GB DDR4, one PCIe x16 slot, four SATA III ports, Intel Gigabit LAN and Realtek 7.1 audio

  • CPU Socket TypeLGA1200
  • CPU Type1. Support LGA1200 slot - 10th generation processor: Intel C
  • ChipsetIntel B460
  • Maximum Memory Supported128 GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID1XM.2 interface, 4xSATA III interface
  • Supports 10th Gen Intel Core, Pentium and Celeron processors on LGA1200 socket
  • Up to 128 GB DDR4 across four DIMM slots for heavy multitasking
  • PCI Express x16 slot runs at full x16 speed for graphics cards
  • Intel Gigabit LAN and Realtek 7.1-channel audio built in
  • Micro-ATX 24.4 cm board fits compact cases with 6 USB 3.2 Gen 1 ports

Socket and Chipset

The board uses the Intel B460 chipset and an LGA1200 socket, supporting 10th generation Intel Core i9, i7, i5, i3, Pentium and Celeron processors. It is built in a Micro ATX form factor measuring 24.4 by 24.4 cm and includes four DDR4 DIMM slots.

Memory Capacity

Maximum supported memory is 128 GB across the four DDR4 slots. The layout also provides one PCI Express x16 slot running at x16 electrical, one M.2 interface and four SATA III ports for storage expansion.

Sustained Operation

A Realtek audio codec delivers up to 7.1 channel high definition sound while an Intel GbE LAN controller handles 1 Gbit and 100 Mbit wired networking. Rear I/O includes three USB 3.2 Gen 1 ports and two USB 2.0 ports, with internal headers adding two more USB 3.2 Gen 1 and four USB 2.0 connections.

Highlights

  • Supports 10th Gen Intel Core, Pentium and Celeron processors on LGA1200 socket
  • Up to 128 GB DDR4 across four DIMM slots for heavy multitasking
  • PCI Express x16 slot runs at full x16 speed for graphics cards
  • Intel Gigabit LAN and Realtek 7.1-channel audio built in
  • Micro-ATX 24.4 cm board fits compact cases with 6 USB 3.2 Gen 1 ports

Specifications

BrandGIGABYTE
SeriesGIGABYTE GA-B460M DS3H V2
ModelGIGABYTE GA-B460M DS3H V2
CPU Socket TypeLGA1200
CPU Type1. Support LGA1200 slot - 10th generation processor: Intel Core ™ i9 processor/Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor/Intel Pentium processor/Intel Celeron processor ®
2. L3 cache depends on CPU
ChipsetIntel B460
Maximum Memory Supported128 GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
3. 2 PCI Express x1 slots
All PCI Express slots support PCI Express 3.0.
SATA RAID1XM.2 interface, 4xSATA III interface
Audio Chipset1. Built-in Realtek sound chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
* To start the 7.1 channel audio output, you must enter the audio software to change the default value of "Advanced Device Settings > Playback Device". Please check the detailed setting instructions on the Gigabyte website.
LAN ChipsetBuilt-in Intel GbE network chip (1 Gbit/100 Mbit)
Onboard USBBuilt-in chipset:
1.5 USB 3.2 Gen 1 ports (3 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
2.6 USB 2.0/1 ports (2 on the rear panel, 4 to be connected from the USB socket in the main board via cable)

Questions about this item

What does the 128 GB maximum memory mean for a working system?

The board supports up to 128 GB of DDR4 across its four DIMM slots, so you can fill all four slots to reach the maximum capacity.

What does the PCI Express x16 slot running at x16 actually cap for a graphics card?

The PCIEX16 slot operates at x16 electrical, giving a graphics card the full lane bandwidth the chipset provides.

What clearance and mounting points does the 24.4 cm Micro ATX board need?

The board measures 24.4 cm by 24.4 cm and uses standard Micro ATX screw holes, so it fits any case with Micro ATX or larger motherboard support.
