Green Micro ATX board with silver LGA 1151 socket, two black DDR4 slots, blue PCIe x16 slot, two white PCIe x1 slots

GIGABYTE

GIGABYTE H310M H 2.0 LGA 1151 Intel H310 Micro ATX Motherboard

SKU CH-N81R-2Y67H

Micro-ATX board for 8th and 9th Gen Intel CPUs, dual-channel DDR4 to 32 GB, one PCIe 3.0 x16 slot, four SATA ports, HDMI and D-Sub video, Gigabit LAN

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU TypeSupport for 9th and 8th Generation Intel Core i9/i7/i5/i3 pr
  • ChipsetIntel H310
  • Onboard Video ChipsetIntegrated Graphics Processor-Intel HD Graphics support: 1 x
  • Number of Memory Slots2x288pin (DDR4)
  • Memory StandardDDR4 2666/ 2400/ 2133 MHz memory modules Support for ECC Un-
  • Supports 9th and 8th Gen Intel Core processors with LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • HDMI 1.4 output drives 4096 x 2160 at 30 Hz
  • Four SATA 6Gb/s ports for HDD or SSD storage
  • Realtek ALC887 audio delivers 7.1-channel surround sound

LGA 1151 300 Series Micro ATX Board

This GIGABYTE H310M H 2.0 motherboard fits the LGA 1151 300 Series socket and the Micro ATX form factor. It is built for 8th and 9th Generation Intel Core i9, i7, i5 and i3 processors as well as Pentium and Celeron CPUs in the same package. The Intel H310 chipset provides the core platform features for a compact desktop build.

Budget Builders and Legacy Upgraders

The board suits builders assembling a cost-conscious office or home PC with a supported 8th or 9th Generation Intel processor. It will not accept older LGA 1151 CPUs, so anyone reusing a 6th or 7th Generation chip must choose a different motherboard. Overclocking features are absent, limiting appeal for enthusiasts seeking multiplier control.

32 GB DDR4 Dual Channel and Four SATA Drives

Two DDR4 DIMM slots support up to 32 GB of memory running at 2133, 2400 or 2666 MHz in dual channel mode. Four SATA 6Gb/s ports give room for multiple hard drives or SSDs. A single PCI Express 3.0 x16 slot handles one graphics card while two PCI Express 2.0 x1 slots remain for add-in cards.

Highlights

  • Supports 9th and 8th Gen Intel Core processors with LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • HDMI 1.4 output drives 4096 x 2160 at 30 Hz
  • Four SATA 6Gb/s ports for HDD or SSD storage
  • Realtek ALC887 audio delivers 7.1-channel surround sound

Specifications

BrandGIGABYTE
ModelH310M H 2.0
CPU Socket TypeLGA 1151 (300 Series)
CPU TypeSupport for 9th and 8th Generation Intel Core i9/i7/i5/i3 processors / Intel Pentium processors / Intel Celeron processors in the LGA1151 package
* Not backward compatible with older generation of LGA 1151 CPUs
ChipsetIntel H310
Onboard Video ChipsetIntegrated Graphics Processor-Intel HD Graphics support:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.2.
Maximum shared memory of 1GB
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2666/ 2400/ 2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
* To support 2666 MHz or XMP memory, you must install an 8th Generation Intel Core i7/i5 processor.
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
PCI Express x12 x PCI Express x1 slots
(The PCI Express x1 slots conform to PCI Express 2.0 standard.)
Serial ATA (SATA)4 x SATA 6Gb/s
Audio ChipsetRealtek ALC887
Audio Channels2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
LAN ChipsetRealtek GbE LAN chip
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x HDMI port
2 x USB 3.1 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB 3.1 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module (TPM) header (2x6-pin, for the GC-TPM2.0_S module only)
1 x Clear CMOS jumper
Form FactorMicro ATX
Dimensions (W x L)8.9" x 6.9"
Power Pin1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
FeaturesI/O Controller:
iTE I/O Controller Chip
H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS:
1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features:
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
3D OSD
@BIOS
Aut

Questions about this item

Do I need an 8th or 9th Generation Intel Core processor in the LGA 1151 package for this board to work?

Yes, the LGA 1151 (300 Series) socket only accepts 8th and 9th Generation Intel Core i9, i7, i5, i3, Pentium and Celeron CPUs in the LGA1151 package. It is not backward compatible with older LGA 1151 processors.

Can I keep my existing DDR4 2400 MHz memory modules when upgrading to this motherboard?

Yes, the board supports DDR4 2666, 2400 and 2133 MHz unbuffered DIMMs up to 32 GB across two slots running in dual-channel mode.

How do I verify the HDMI output is running at 4096x2160@30 Hz after assembly?

Connect a display to the HDMI port, boot into Windows 10, open Display Settings and confirm the resolution shows 4096x2160 at 30 Hz. The port follows HDMI 1.4 specification.
