Silver 1U rack server with eight front drive bays

HP

HP ProLiant DL360 Gen9 1U rack server 2× E5-2640 v3 2.6GHz 32GB 2× 600GB SAS H240ar

SKU CH-05XJ-TBQP2

1U rack server with dual 8-core Xeon E5-2640 v3 CPUs, 32GB DDR4, two 600GB 15K SAS drives and H240ar RAID controller

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Dual 8-core Xeon processors deliver 16 cores at 2.6GHz
  • 32GB DDR4 ECC memory supports demanding workloads
  • Two 600GB 15K SAS drives provide fast storage
  • H240ar controller enables RAID 0/1/5/6/10/50/60
  • Redundant 500W hot-swap power supplies ensure uptime

Dense 1U rack server

The HP ProLiant DL360 Gen9 fits two Intel Xeon E5-2640 v3 processors and 32GB of DDR4 memory into a single rack unit. Redundant 500W hot-swap power supplies keep the system running through a module failure. It is built for compute clusters, virtualization hosts or database nodes that need high core density in limited rack space.

Eight SFF bays with H240ar RAID

Eight 2.5-inch drive bays connect to the Smart HBA H240ar controller which supports RAID 0, 1, 5, 6, 10, 50 and 60 across 12Gb SAS and 6Gb SATA links. Two 600GB 15K SAS drives are installed; the remaining six bays accept additional SAS or SATA drives. The controller replaces a basic HBA and makes the jump worthwhile when you need hardware RAID without a separate PCIe card.

Check processor generation and memory limits

The board uses the Intel C610 chipset and only accepts Xeon E5 v3 or v4 CPUs; installed memory runs at speeds the processors support up to 2400MT/s. Twenty-four DIMM slots are present but the current configuration already reaches the 32GB installed capacity listed, so further expansion requires replacing modules. Verify that your rack depth, rail kit and operating-system licensing match a 1U server with Matrox G200 graphics and no optical drive.

Highlights

  • Dual 8-core Xeon processors deliver 16 cores at 2.6GHz
  • 32GB DDR4 ECC memory supports demanding workloads
  • Two 600GB 15K SAS drives provide fast storage
  • H240ar controller enables RAID 0/1/5/6/10/50/60
  • Redundant 500W hot-swap power supplies ensure uptime

Specifications

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity32GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What rack height and drive-bay layout does the DL360 Gen9 use for mounting?

The server is a 1U rack unit with 8 SFF drive bays; it mounts in a standard rack using the rail kit designed for the DL360 Gen9 chassis.

How are the two Xeon E5-2640 v3 processors and the 32 GB of DDR4 memory installed, and what step is often missed?

Both CPUs are pre-installed; populate the 24 DIMM slots evenly across the 12 slots per processor so each memory channel is balanced.

Which components will need replacement first — the 600 GB 15K SAS drives or the 500 W redundant power supplies?

The 600 GB 15K SAS drives typically wear out before the 500 W redundant power supplies; keep spare 2.5-inch SAS drives on hand.
