HP Z8 G4 tower workstation in silver finish

HP

HP Z8 G4 2x Xeon Gold 6136 96GB 1TB NVMe P4000 Workstation

SKU CH-6A3T-TACAE

Dual Xeon Gold 6136 workstation with 96GB DDR4 ECC, 1TB NVMe storage and Quadro P4000 8GB GDDR5 for CAD and rendering

  • TypeTower
  • Redundant Hot-swap PowerNo
  • CPU TypeIntel Xeon Gold
  • MAX Processors2
  • Chipset1125W
  • Installed Memory Size96GB

Installed Memory Size 96GB

  • 16GB
  • 32GB
  • 48GB
  • 64GB
  • 96GB
  • 128GB
  • 192GB
  • 256GB
  • 384GB
  • 768GB
  • 1.5TB

Struck-through versions exist but are not stocked here.

SSD (Installed) 1TB

Struck-through versions exist but are not stocked here.

  • Dual 12-core Xeon Gold 6136 CPUs deliver 24 cores for heavy workloads
  • 96GB DDR4 ECC memory across 24 slots supports large datasets
  • 1TB NVMe SSD plus RAID 0/1/10 provides fast protected storage
  • NVIDIA Quadro P4000 with 8GB GDDR5 drives professional visual tasks
  • Six-channel 2666MHz memory architecture maximises bandwidth with dual processors

Dual Xeon Gold 6136 tower workstation

The HP Z8 G4 tower ships with two Intel Xeon Gold 6136 processors, each running at 3.00 GHz with twelve cores. Twenty-four physical cores and forty-eight threads handle design, rendering, engineering and data-heavy workloads. Ninety-six gigabytes of DDR4 ECC memory fill the maximum supported capacity across twenty-four DIMM slots. A 1 TB NVMe SSD on a PCIe adapter card provides the primary boot and application drive.

NVIDIA Quadro P4000 and Windows 10 Pro

The installed NVIDIA Quadro P4000 graphics card brings 8 GB of GDDR5 memory and four Mini DisplayPort 1.4 outputs for multi-display CAD and content-creation setups. Windows 10 Professional 64-bit is pre-installed for an out-of-box experience. The chassis includes a DVD+/-RW drive in a dedicated 9.5 mm slim bay and four internal 3.5-inch bays with acoustic dampening rails for additional SATA storage.

Expansion slots and power before ordering

Slot 1 runs at PCIe Gen3 x4 and converts to x8 when the second CPU is present; Slots 2 and 4 are full Gen3 x16, while Slot 3 becomes available only with the second processor installed. Four 6+2-pin graphics power cables are included for up to four full-length cards. The 1125 W power supply is not redundant and does not support hot-swap replacement.

Highlights

  • Dual 12-core Xeon Gold 6136 CPUs deliver 24 cores for heavy workloads
  • 96GB DDR4 ECC memory across 24 slots supports large datasets
  • 1TB NVMe SSD plus RAID 0/1/10 provides fast protected storage
  • NVIDIA Quadro P4000 with 8GB GDDR5 drives professional visual tasks
  • Six-channel 2666MHz memory architecture maximises bandwidth with dual processors

Specifications

BrandHP
SeriesZ Series
ModelZ8 G4
TypeTower
Redundant Hot-swap PowerNo
CPU TypeIntel Xeon Gold
MAX Processors2
Chipset1125W
Installed Memory Size96GB
Memory TypeDDR4
Max Memory Capacity96GB
Memory FeaturesSix channel memory up to 2666MHz DDR4 ECC memory with dual CPUs, 24 DIMM Slots (12 DIMMs per CPU).
Number of Memory Slots24
SSD (Installed)1TB
Raid LevelRAID 0/1/10
Media DrivesDVD +/- RW
GPU TypeNVIDIA Quadro P4000
Video Memory5GB
LAN Ports2 x Ports
Expansion SlotsSlot 1: PCIe Gen3 x4 - Transforms to PCIe Gen3 x8 when 2nd CPU is installed, Slot 2: PCIe Gen3 x16, Slot 3: PCIe Gen3 x16 - Available ONLY when 2nd processor is installed, Slot 4: PCIe Gen3 x16, Slot 5: PCIe Gen3 x4, Slot 6: PCIe Gen3 x16 - Available ONLY when 2nd processor is installed, and Slot 7: PCIe Gen3 x4
Operating SystemWindows 10 Pro 64
Weight45.0000LBS

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much additional DDR4 ECC memory can be added to the 24 DIMM slots beyond the installed 96GB?

The six-channel DDR4 ECC architecture supports up to 3TB total across 24 slots with dual CPUs installed.

What sustained workload constraint appears first when both Xeon Gold 6136 processors and the Quadro P4000 run continuously?

The 1125W power supply delivers the hard ceiling for combined CPU and GPU thermal design power under full load.

How loud are the fans and what heat output should be expected when the workstation runs all day?

Four internal 3.5-inch bays include acoustic dampening rails to reduce airflow noise during extended operation.
