Silver 1U rack server front panel with eight drive bays

HPE

HPE ProLiant DL320 G11 1U Rack Server P57688-B21 1x Xeon 5416S 2.0 GHz 16-Core 32 GB DDR5 8 SFF 500 W

SKU CH-J1F0-P8HDG MPN P57688-B21

1U rack server with Xeon 5416S 16-core CPU, 32 GB DDR5, 8 SFF bays, 500 W PSU

  • TypeRack
  • Rack Height1U
  • SecurityUEFI Secure Boot and Secure Start support Tamper-free update
  • CPU TypeIntel Xeon Gold
  • CPU Speed5416S (2.0 GHz)
  • Number of CPU Cores16-Core Processor
  • 16-core Xeon 5416S delivers strong compute density
  • 32 GB DDR5 memory scales to 2.04 TB capacity
  • 8 SFF drive bays with MR408i-o controller
  • 1U rack form factor fits dense deployments
  • Silicon Root of Trust with FIPS 140-2 validation

Compact 1U single-socket rack server

The HPE ProLiant DL320 G11 fits in one rack unit and ships with one Intel Xeon Gold 5416S processor running at 2.0 GHz with 16 cores. It includes 32 GB of DDR5 memory and an Intel C741 chipset, plus a single 500 W power supply and eight small-form-factor drive bays.

Suited for virtualisation and edge workloads

This configuration supports up to 2.04 TB of DDR5 across sixteen slots, making it a match for dense virtualisation, software-defined storage or edge AI inference. Buyers who need dual-processor performance or more than eight front drive bays should look at a larger chassis.

16-core Xeon Gold 5416S at 2.0 GHz

The installed CPU defines the compute ceiling for this single-socket system. With sixteen cores at 2.0 GHz it sets the thread count and base frequency for every workload running on the server.

Highlights

  • 16-core Xeon 5416S delivers strong compute density
  • 32 GB DDR5 memory scales to 2.04 TB capacity
  • 8 SFF drive bays with MR408i-o controller
  • 1U rack form factor fits dense deployments
  • Silicon Root of Trust with FIPS 140-2 validation

Specifications

BrandHPE
SeriesProLiant
ModelProLiant DL320 G11
Part NumberP57688-B21
TypeRack
Rack Height1U
SecurityUEFI Secure Boot and Secure Start support
Tamper-free updates - components digitally signed and verified
Immutable Silicon Root of Trust
Ability to rollback firmware
FIPS 140-2 validation
Secure erase of NAND/User data
Common Criteria certification
Configurable for PCI DSS compliance
Embedded TPM (Trusted Platform Module) 2.0. Excluded for shipments to China.
Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
Bezel Locking Kit option
Support for Commercial National Security Algorithms (CNSA)
Chassis Intrusion detection option
Secure Recovery - re
CPU TypeIntel Xeon Gold
CPU Speed5416S (2.0 GHz)
Number of CPU Cores16-Core Processor
# of Processors Installed1
ChipsetIntel C741
Installed Memory Size32GB
Memory TypeDDR5
Max Memory Capacity2TB
Number of Memory Slots16
Storage ControllerMR408i-o
Expansion Bays8
Compatible/Certified OSWindows Server
Red Hat Enterprise Linux
SuSE Linux Enterprise Server
Ubuntu
Oracle Linux
Citrix XenServer
CentOS
DimensionsHeight:
1.7"
Width:
17.1"
Depth:
23.8"
Weight36.84 lb
Package ContentsProLiant DL320 Gen11 5416S 2.0GHz 16-core 1P 32GB-R MR408i-o 8SFF 500W PS Server
Rail Kit
6-foot IEC C-13/C-14 Jumper Cord
Shipping weight4.54 kg
Package size508 × 508 × 305 mm

Questions about this item

What rack depth is needed to fit the 1U chassis that is 23.8 inches deep?

The server is 23.8 inches deep, so a standard 1U rack with at least that much usable depth will accommodate it.

How is the MR408i-o storage controller installed, and what step is often missed?

The MR408i-o controller is pre-installed; the step often missed is configuring the logical drives in the controller BIOS before installing the operating system.

When will the DDR5 memory modules need replacement?

DDR5 modules typically last the server's lifecycle; replacement is only needed if a module fails or capacity must exceed the 32 GB installed across the 16 slots.
