HPE
HPE ProLiant DL360 Gen9 4LFF 2x Xeon E5-2640 v3 2.6GHz 256GB DDR4 rack server
A 1U rack server with dual Xeon E5-2640 v3 processors at 2.6GHz, 256GB DDR4 ECC memory, a P440 SAS controller and four 3.5-inch drive bays, sold without drives
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.6GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size256GB
- Dual Xeon E5-2640 v3 processors provide 2.6GHz clock speed for multi-threaded workloads
- 256GB DDR4 ECC registered memory supports virtualization density and large datasets
- HPE Smart Array P440 SAS controller enables RAID across SATA drives
- Four 3.5-inch drive bays allow flexible storage capacity planning
- HPE iLO Advanced remote management simplifies out-of-band server administration
Dual-socket Xeon rack server
The HPE ProLiant DL360 Gen9 fits a 1U rack slot and ships with two Xeon E5-2640 v3 processors running at 2.6 GHz. Its 256 GB of DDR4 ECC registered memory supports virtualisation clusters and database workloads that need high core counts and error-correcting RAM. The four 3.5-inch drive bays accept SATA or SAS media through the onboard P440 controller, while dual 500 W flex-slot power supplies provide redundancy. Remote management is handled by HPE iLO Advanced.
Sustained-load behaviour
Under continuous multi-threaded load the dual eight-core CPUs maintain their 2.6 GHz base frequency without thermal throttling, thanks to the 1U airflow design and redundant 500 W power modules. The P440 SAS controller keeps RAID arrays consistent during long rebuilds, and ECC memory corrects single-bit errors in real time so databases stay online. Dual 10 GbE and dual 1 GbE ports sustain high-throughput east-west traffic without saturating a single link.
Pre-order checklist
Confirm your rack provides a 1U space with front-to-rear airflow and that the 36-inch depth clears cable managers and PDUs. Verify the facility can deliver two independent 500 W feeds to match the redundant power supplies. Plan storage separately — no drives are included — and ensure any SATA or SAS disks you add are compatible with the P440 controller. Check that your network core has 10 GbE uplinks to use the dual X540 ports.
Highlights
- Dual Xeon E5-2640 v3 processors provide 2.6GHz clock speed for multi-threaded workloads
- 256GB DDR4 ECC registered memory supports virtualization density and large datasets
- HPE Smart Array P440 SAS controller enables RAID across SATA drives
- Four 3.5-inch drive bays allow flexible storage capacity planning
- HPE iLO Advanced remote management simplifies out-of-band server administration
Specifications
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.6GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 256GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 768GB |
| Hard Drive (Installed) | 8,00 |
| Storage Controller | HPE Smart Array P440 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
How loud and hot does the DL360 Gen9 run with both Xeon E5-2640 v3 CPUs at full load all day?
Dual 500 W Flex Slot supplies feed the 2.6 GHz processors; fan speed ramps with CPU temperature so sustained load increases airflow and heat output.
Which drives and caddies do I need to add before the P440 controller can present storage to the OS?
The 4 LFF bays accept 3.5" SATA drives; the server ships without drives or caddies so you must supply both.
Will my existing SAS tape library connect straight to the P440 RAID card in this Gen9 box?
The P440 provides internal SAS lanes only; external tape devices require a separate HBA with external ports.
