HPE ProLiant DL380 Gen9 12LFF 1x Xeon E5-2620 v3 192GB DDR4 rack server
A 12-bay 3.5-inch rack server with one Xeon E5-2620 v3 at 2.4GHz, 192GB DDR4, P440ar SAS controller and dual 800W supplies
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.4GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size192GB
- 12 LFF drive bays support high-capacity 3.5" storage
- 192 GB DDR4 ECC memory handles demanding workloads
- Dual 800 W hot-plug power supplies keep the system running
- Intel I350 and X540 network adapters deliver 10 GbE and 1 GbE connectivity
- HPE iLO Advanced remote management simplifies server administration
HPE DL380 Gen9 12-bay rack server
This 2U rack system ships with a single Xeon E5-2620 v3 processor running at 2.4 GHz and 192 GB of DDR4 ECC registered memory. The chassis provides twelve 3.5-inch large-form-factor drive bays and includes an HP Smart Array P440ar controller with SAS expander for SATA drives. Remote management is handled by HPE iLO Advanced and dual 800 W hot-plug power supplies are fitted.
Suited for storage-heavy workloads needing many
Organisations that need dense 3.5-inch storage capacity with room to grow to a second processor will fit this platform. Buyers who require pre-installed drives or a fully populated CPU socket should look at a different configuration. The integrated graphics and dual 10 GbE plus dual 1 GbE network card cover basic console and connectivity needs.
Twelve 3.5-inch bays with P440ar SAS controller
The defining specification is the twelve-bay LFF chassis paired with the P440ar RAID controller and SAS expander, which dictates how many SATA drives can be installed and managed. Memory can scale to 3 TB across DDR4 slots and a second Xeon can be added later, but the bay count and controller are fixed by the chassis.
Highlights
- 12 LFF drive bays support high-capacity 3.5" storage
- 192 GB DDR4 ECC memory handles demanding workloads
- Dual 800 W hot-plug power supplies keep the system running
- Intel I350 and X540 network adapters deliver 10 GbE and 1 GbE connectivity
- HPE iLO Advanced remote management simplifies server administration
Specifications
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.4GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 192GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 3TB |
| Hard Drive (Installed) | 8,00 |
| Storage Controller | HP Smart Array P440ar And Sas Expander |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
How loud is the HPE ProLiant DL380 Gen9 with dual 800W supplies running 24/7?
Dual 800W Flex Slot hot-plug supplies share the load, keeping fan speeds lower during continuous operation.
What drives and caddies must I supply for the 12-bay 3.5-inch chassis?
The 12 LFF bays accept 3.5-inch SATA drives; the P440ar SAS controller manages them, but no drives or caddies are installed.
Will my existing DDR4 ECC registered modules work with the single Xeon E5-2620 v3 installed?
Yes, the 192GB already installed is DDR4 ECC registered; adding matching modules will run at the CPU's supported memory speed.
