Green rectangular M.2 2280 SSD circuit board with gold edge connector and black controller chip

HUADISK

HUADISK HYV2TBX4(GR) 2TB M.2 2280 PCIe 4.0 x4 internal SSD

SKU CH-4APP-NXEK3 MPN HYV2TBX4(GR)

A 2 TB M.2 2280 PCIe 4.0 x4 internal SSD with NVMe 1.4 delivering up to 7100 MBps read, 5700 MBps write, 720000 IOPS random read and 800000 IOPS random write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe 1.4

Capacity 2TB

  • Sequential read up to 7100 MBps accelerates boot and file loads
  • Sequential write up to 5700 MBps speeds large-file creation
  • Random read up to 720000 IOPS keeps multitasking responsive
  • Random write up to 800000 IOPS handles heavy write workloads
  • 1200 TBW and 1000000-hour MTBF indicate long service life

2TB M.2 2280 PCIe 4.0 x4 SSD

This HUADISK internal solid-state drive delivers 2TB of NVMe storage in the M.2 2280 form factor. It connects through a PCIe 4.0 x4 interface and is suited to desktops, laptops and the PS5 where a heatsink-less module is required.

Capacity and headroom

Sequential reads reach up to 7100 MBps and writes up to 5700 MBps, while random performance hits 720000 IOPS read and 800000 IOPS write. The 1200 TBW endurance rating and 1000000 hour MTBF provide headroom for heavy workloads, though sustained writes will eventually throttle without a heatsink.

PCIe 4.0 x4 interface limits

The drive operates within the NVMe 1.4 specification over four PCIe 4.0 lanes, capping theoretical throughput at the rated sequential speeds. Power draw ranges from .66W idle to 8.18W active, and the operating window spans 0°C to 70°C.

Highlights

  • Sequential read up to 7100 MBps accelerates boot and file loads
  • Sequential write up to 5700 MBps speeds large-file creation
  • Random read up to 720000 IOPS keeps multitasking responsive
  • Random write up to 800000 IOPS handles heavy write workloads
  • 1200 TBW and 1000000-hour MTBF indicate long service life

Specifications

BrandHUADISK
ModelHYV2TBX4(GR)
Part NumberHYV2TBX4(GR)
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
InterfacePCI-Express 4.0 x4
ProtocolNVMe 1.4
Max Sequential ReadUp to 7100 MBps
Max Sequential WriteUp to 5700 MBps
4KB Random ReadUp to 720,000 IOPS
4KB Random WriteUp to 800,000 IOPS
Terabytes Written (TBW)1200TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)0.66W
Power Consumption (Active)8.18W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5-95%
Height80.0mm
Width22.0mm
Depth2.10mm
Weight30g
Shipping weight0.05 kg
Package size98 × 64 × 17 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does this drive fit in a PlayStation 5 expansion slot?

Yes. The M.2 2280 form factor and PCIe 4.0 x4 interface match the PS5 requirements, and the drive has no heatsink so you can add Sony's own cover or a third-party one.

Will my laptop's M.2 slot support the full 7100 MB/s read speed?

Only if the laptop provides a PCIe 4.0 x4 link; on a PCIe 3.0 slot the drive will still work but sequential reads will be limited to the slot's lower bandwidth.

Is a separate heatsink necessary for sustained heavy workloads?

The drive ships without one; for long writes in a confined chassis adding a thin aftermarket heatsink keeps temperatures inside the 0-70 °C operating range.
