Green ATX motherboard with silver heatsinks and black slots

HUANANZHI

HUANANZHI X79 DELUXE V7.1 Intel motherboard LGA 2011

SKU CH-H74Y-MV0ET

ATX board for LGA 2011 Xeon CPUs with four-channel DDR3, dual PCIe 3.0 x16 slots, M.2 NVME, USB 3.0 and 7.1 audio

  • CPU Socket TypeLGA 2011
  • CPU TypeLGA 2011
  • Supports Xeon E5 processors up to 2690 for high core-count workloads
  • Four-channel DDR3 memory up to 1866 MHz with REG ECC and non-ECC options
  • Dual PCI-E 3.0 x16 slots enable multi-GPU configurations for compute or rendering
  • Six SATA ports including two SATA 3.0 for fast storage arrays
  • ALC892 7.1-channel audio delivers clear multi-channel output

Socket LGA 2011 workstation board

The HUANANZHI X79 DELUXE V7.1 is an ATX motherboard built around the Intel X79 chipset for LGA 2011 Xeon E5 processors. It targets builders who need a multi-core platform for rendering, virtualization or compute workloads on a mature socket. Four-channel DDR3 memory support and multiple expansion slots give flexibility for add-in cards and storage arrays. The board ships without integrated graphics so a discrete GPU is required.

Thermals noise and power draw

An eight-layer PCB helps distribute current across the 7-phase power delivery for stable operation under sustained loads. The supplier notes that the platform demands strong power and recommends at least a 500 W unit to keep voltages steady. No fan headers or cooling specifications are provided so acoustic profile depends on the chosen CPU cooler and case airflow. Gigabit Ethernet and the ALC892 7.1-channel audio codec add minimal heat.

Expansion slots and connectivity

Two PCI-E 3.0 x16 slots, two PCI-E 4x slots and one PCI-E 1x slot accommodate graphics cards, capture cards or high-speed NICs. Six USB 3.0 ports and ten USB 2.0 ports (including internal headers) provide ample peripheral bandwidth. Storage options include two SATA 3.0 ports, four SATA 2.0 ports and an M.2 slot that supports NVME SSDs as well as Wi-Fi modules. The board measures 305 x 220 mm and fits standard ATX cases.

Highlights

  • Supports Xeon E5 processors up to 2690 for high core-count workloads
  • Four-channel DDR3 memory up to 1866 MHz with REG ECC and non-ECC options
  • Dual PCI-E 3.0 x16 slots enable multi-GPU configurations for compute or rendering
  • Six SATA ports including two SATA 3.0 for fast storage arrays
  • ALC892 7.1-channel audio delivers clear multi-channel output

Specifications

BrandHUANANZHI
ModelX79 DELUXE
CPU Socket TypeLGA 2011
CPU TypeLGA 2011

Questions about this item

How do I mount the 305x220 mm ATX board and connect its power headers?

Align the board with standard ATX standoffs in the case, secure it with screws, then attach the 24-pin ATX and 8-pin CPU power connectors from a supply rated at least 500 W.

What maintenance will the board need after installation?

The onboard CMOS battery is removed before shipping; you must install a replacement cell to keep BIOS settings and the system clock running.

What limit appears first when the X79 chipset runs sustained heavy I/O?

The two SATA 3.0 ports max out at 6 Gbps each, so high-throughput NVMe or RAID arrays will saturate them before the four SATA 2.0 ports become a factor.
