Compact black mini PC barebone with slim chassis, VESA mount and multiple ports

Intel

Intel NUC14RVKi3 barebone mini PC Core 3 100U 16GB 1TB

SKU CH-BAYY-49C1H MPN NUC14RVKi3

A compact barebone mini PC with an Intel Core 3 100U processor, 16 GB DDR5 memory and a 1 TB NVMe SSD, ready for multi-display setups

  • ColorBlack
  • Form FactorSlim
  • CPU TypeIntel Core 3
  • Memory installedNo Memory
  • Memory Type SupportedDDR5 5600
  • Max Memory Supported96GB

Group 16gb ram / 1tb ssd

  • Compact 117×112×37 mm chassis fits tight spaces
  • Intel Core 3 100U with 6 cores up to 4.70 GHz
  • Dual-channel DDR5-5600 memory up to 96 GB
  • Two Thunderbolt 4 and two HDMI 2.1 ports drive four displays
  • 5 Gbps Ethernet plus Wi-Fi 6E AX211 and Bluetooth 5.3

Slim barebone with Core 3 100U

This Intel NUC 14 Pro barebone ships as a 117 x 112 x 37 mm chassis that includes a soldered Core 3 100U processor with six cores, eight threads and a 4.70 GHz maximum turbo. Two SO-DIMM slots accept DDR5-5600 memory up to 96 GB total while one M.2 2280 and one M.2 2242 slot provide NVMe storage expansion. Integrated Intel Graphics with 64 execution units drives up to four displays via two HDMI 2.1 ports and two Thunderbolt 4 ports.

Who this suits and who it does not

Builders who want a compact, VESA-mountable desktop for office productivity, digital signage or light development will appreciate the 2.5 GbE LAN, Wi-Fi 6E and the 90 W 19 V adapter included in the box. Buyers who need discrete graphics performance, more than four simultaneous displays or a pre-installed operating system should look elsewhere.

Deciding specification: dual Thunderbolt 4

The combination of two Thunderbolt 4 Type-C ports and two HDMI 2.1 (TMDS) outputs enables four-display configurations at up to 8K 60 Hz from the integrated graphics. If your workflow requires that specific quad-display connectivity, this barebone meets it; if you need different video outputs, another platform will be required.

Highlights

  • Compact 117×112×37 mm chassis fits tight spaces
  • Intel Core 3 100U with 6 cores up to 4.70 GHz
  • Dual-channel DDR5-5600 memory up to 96 GB
  • Two Thunderbolt 4 and two HDMI 2.1 ports drive four displays
  • 5 Gbps Ethernet plus Wi-Fi 6E AX211 and Bluetooth 5.3

Specifications

BrandIntel
SeriesNUC (Next Unit of Computing)
ModelNUC14RVKi3
ColorBlack
Form FactorSlim
CPU TypeIntel Core 3
Memory installedNo Memory
Memory Type SupportedDDR5 5600
Max Memory Supported96GB
Dual Channel Memory SupportedYes
Storage InstalledNo Hard Drive
LANIntel i226-LM
Max LAN Speed2.5Gbps
BluetoothBluetooth 5.3
HDMI2
Rear USB4
RJ451

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How loud and hot does the NUC14RVKi3 get when the Core 3 100U runs at 4.70 GHz all day?

The slim chassis measures 117 x 112 x 37 mm and uses a 90W 19V adapter; the integrated Intel Graphics run at 1.25 GHz and the 2.5G Ethernet (i226-LM) stays active without extra fan noise reported.

Which DDR5 SO-DIMMs and M.2 NVMe drives must I supply to complete this barebone?

Install two DDR5-5600 SO-DIMMs up to 48 GB each for 96 GB total, plus one M.2 2280 PCIe Gen4x4 NVMe and one M.2 2242 PCIe x4 NVMe for storage.

Will my older USB 3.2 Gen 1 peripherals and 1080p monitors work with the Thunderbolt 4 and HDMI 2.1 ports?

Yes, the two Thunderbolt 4 Type-C ports and two HDMI 2.1 (TMDS) ports are backward compatible with USB 3.2 Gen 1 devices and 1080p displays while still driving up to four screens.
