Square green ceramic CPU with gold contact pads and silver heat spreader marked Intel Xeon Gold 6454S

Intel

Intel PK8071305073001 Xeon Gold 6454S server processor 32-core 2.2 GHz 60 MB L3

SKU CH-1A0D-13KRP MPN PK8071305073001

32-core server processor running at 2.2 GHz with 60 MB L3 cache and DDR5 4800 MT/s support

  • NameXeon Gold 6454S
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores32-Core
  • # of Threads64
  • Operating Frequency2.2 GHz
  • 32 cores and 64 threads handle parallel workloads efficiently
  • 2 GHz base frequency with 3.4 GHz max turbo adapts to demand
  • 60 MB L3 cache reduces latency for large datasets
  • 8-channel DDR5 up to 4800 MT/s feeds cores with high bandwidth
  • 80 PCIe 5.0 lanes connect fast storage and accelerators

Server Processor for Dual-Socket Platforms

The Intel Xeon Gold 6454S is a 32-core server processor built for dual-socket platforms. It delivers 64 threads at a 2.2 GHz base frequency with a 3.4 GHz maximum turbo frequency. The 60 MB L3 cache supports data-intensive workloads on a 10 nm Sapphire Rapids core.

Suited for Memory-Bound Workloads.

This processor suits environments that need eight-channel DDR5 memory up to 4 TB capacity and 80 lanes of PCI Express 5.0 connectivity. Buyers who prioritise single-thread speed or require lower thermal output should evaluate alternatives. Cooling is not included.

270 W Thermal Design Power Defines Cooling

The 270 W TDP is the primary specification that determines whether this part fits a given chassis and cooling solution. System integrators must ensure their infrastructure can sustain this heat load before deployment.

Highlights

  • 32 cores and 64 threads handle parallel workloads efficiently
  • 2 GHz base frequency with 3.4 GHz max turbo adapts to demand
  • 60 MB L3 cache reduces latency for large datasets
  • 8-channel DDR5 up to 4800 MT/s feeds cores with high bandwidth
  • 80 PCIe 5.0 lanes connect fast storage and accelerators

Specifications

BrandIntel
SeriesIntel Xeon Gold
NameXeon Gold 6454S
ModelPK8071305073001
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores32-Core
# of Threads64
Operating Frequency2.2 GHz
Max Turbo Frequency3.4 GHz
L3 Cache60MB
64-Bit SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedUp to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability2S
PCI Express Revision5.0
Max # of PCI Express Lanes80
Thermal Design Power270W
Cooling DeviceCooling device not included - Processor Only
Shipping weight0.23 kg
Package size127 × 102 × 25 mm

Questions about this item

What socket and cooler clearance does the Xeon Gold 6454S require?

The processor uses the LGA 4677 socket and has a 270 W thermal design power, so the motherboard must provide that socket and the cooler must be rated for at least 270 W.

Which installation step is most often missed with this LGA 4677 CPU?

The carrier frame must be fully seated and the load plate torqued in the prescribed sequence; skipping a torque step leaves uneven contact and prevents the system from posting.

When will the thermal interface material on the 6454S need replacement?

Replace the paste whenever the cooler is removed or if temperatures rise above normal after several years of continuous operation.
