Square green ceramic processor with gold contact pads and silver heat spreader, LGA 4677 socket form factor

Intel

Intel Xeon Platinum 8470 server processor PK8071305072401 52-core 2.0 GHz 105 MB L3 cache LGA 4677 350 W

SKU CH-24VJ-5BFXA MPN PK8071305072401

52-core server CPU with 104 threads, 2.0 GHz base, 3.80 GHz max turbo, 105 MB L3 cache, 8-channel DDR5 support up to 4 TB, 80 PCIe 5.0 lanes, LGA 4677 socket, 350 W TDP

  • NameXeon Platinum 8470
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores52-Core
  • # of Threads104
  • Operating Frequency2.0 GHz
  • 52 cores and 104 threads handle heavy parallel workloads
  • 0 GHz base clock with 3.80 GHz max turbo frequency
  • 105 MB L3 cache reduces memory latency for large datasets
  • Eight-channel DDR5 controller supports up to 4 TB capacity
  • PCIe 5.0 with 80 lanes enables high-speed I/O expansion

52-Core Xeon for Two-Socket Servers

The Intel Xeon Platinum 8470 is a 52-core server processor built for dual-socket platforms. It targets data-centre workloads that scale across 104 threads, such as virtualisation, database and high-performance computing tasks. The LGA 4677 package fits compatible server motherboards designed for the Sapphire Rapids architecture.

DDR5 Memory Limits at Scale

The integrated controller runs DDR5 at 4800 MT/s with one DIMM per channel and drops to 4400 MT/s when both slots are populated. Eight memory channels support up to 4 TB of total capacity, so maximum bandwidth requires a full complement of single-rank modules. Filling every channel with two DIMMs per channel reduces the per-channel data rate.

PCIe 5.0 Lanes and Thermal Headroom

Eighty PCI Express 5.0 lanes provide connectivity for high-speed storage, networking and accelerator cards in a two-socket configuration. The processor carries a 350 W thermal design power and ships without a cooler, so the platform must supply adequate airflow and a compatible heatsink. Sustained all-core turbo at 3.80 GHz will demand the full cooling budget.

Highlights

  • 52 cores and 104 threads handle heavy parallel workloads
  • 0 GHz base clock with 3.80 GHz max turbo frequency
  • 105 MB L3 cache reduces memory latency for large datasets
  • Eight-channel DDR5 controller supports up to 4 TB capacity
  • PCIe 5.0 with 80 lanes enables high-speed I/O expansion

Specifications

BrandIntel
SeriesIntel Xeon Platinum
NameXeon Platinum 8470
ModelPK8071305072401
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores52-Core
# of Threads104
Operating Frequency2.0 GHz
Max Turbo Frequency3.80 GHz
L3 Cache105MB
64-Bit SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedUp to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability2S
PCI Express Revision5.0
Max # of PCI Express Lanes80
Thermal Design Power350W
Cooling DeviceCooling device not included - Processor Only
Shipping weight0.23 kg
Package size127 × 102 × 25 mm

Questions about this item

Should I choose the 52-core 8470 or a lower-core model for my workload?

The 8470 delivers 52 cores and 104 threads at a 2.0 GHz base frequency, scaling to 3.80 GHz max turbo, suited for heavily parallel server tasks.

What does the 3.80 GHz max turbo frequency mean once the processor is installed in a server?

Under thermal and power headroom, up to 3.80 GHz can be reached on active cores; sustained all-core speeds will settle lower depending on the 350 W TDP and system cooling.

How does the LGA 4677 socket and PCIe 5.0 with 80 lanes affect expansion and memory limits?

LGA 4677 supports 8-channel DDR5 up to 4800 MT/s (1DPC) or 4400 MT/s (2DPC) with a 4 TB maximum, while PCIe 5.0 provides 80 lanes for high-bandwidth add-in cards.
