Intel Xeon Platinum 8480+ server CPU in LGA 4677 package, silver heat spreader with gold contacts

Intel

Intel Xeon Platinum 8480+ PK8071305074801 56-core server processor

SKU CH-9KSC-ZMM89 MPN PK8071305074801

56-core server CPU with 112 threads, 105 MB L3 cache, DDR5-4800 support up to 4 TB, and 80 PCIe 5.0 lanes

  • NameXeon Platinum 8480+
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores56-Core
  • # of Threads112
  • Operating Frequency2.0 GHz
  • 56 cores and 112 threads handle massive parallel workloads
  • 105 MB L3 cache keeps hot data close to execution units
  • Max turbo frequency reaches 3.8 GHz for burst performance
  • Eight-channel DDR5 controller supports up to 4 TB memory capacity
  • 80 lanes of PCIe 5.0 provide high-bandwidth I/O connectivity

56-core Xeon for scale-out servers

The Intel Xeon Platinum 8480+ is a 56-core, 112-thread server processor built on a 10 nm Sapphire Rapids core. It targets dense compute clusters, large virtualisation hosts and memory-heavy analytics workloads that benefit from high core counts and eight-channel DDR5 bandwidth. Buyers needing single-thread speed or workstation-class features should look elsewhere.

LGA 4677 socket, no cooler included

Installation requires a server board with an LGA 4677 socket and a cooling solution rated for 350 W TDP; the processor ships without a heatsink or fan. Common issues include insufficient VRM phases on the motherboard, incorrect mounting pressure on the narrow integrated load mechanism, and BIOS revisions that do not yet support the Sapphire Rapids microcode.

4 TB DDR5 capacity with 80 PCIe 5.0 lanes

Eight memory channels accept up to 4 TB of DDR5 at 4800 MT/s in 1DPC or 4400 MT/s in 2DPC, giving ample headroom for in-memory databases. The 80 PCI Express 5.0 lanes support multiple accelerators or high-speed NICs, but platforms limited to fewer lanes or older PCIe revisions will constrain I/O throughput.

Highlights

  • 56 cores and 112 threads handle massive parallel workloads
  • 105 MB L3 cache keeps hot data close to execution units
  • Max turbo frequency reaches 3.8 GHz for burst performance
  • Eight-channel DDR5 controller supports up to 4 TB memory capacity
  • 80 lanes of PCIe 5.0 provide high-bandwidth I/O connectivity

Specifications

BrandIntel
SeriesIntel Xeon Platinum
NameXeon Platinum 8480+
ModelPK8071305074801
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores56-Core
# of Threads112
Operating Frequency2.0 GHz
Max Turbo Frequency3.8 GHz
L3 Cache105MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedUp to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability2S
PCI Express Revision5.0
Max # of PCI Express Lanes80
Thermal Design Power350W
Cooling DeviceCooling device not included - Processor Only
Shipping weight0.23 kg
Package size127 × 102 × 25 mm

Questions about this item

How can I verify the Xeon Platinum 8480+ is running at its 2.0 GHz base frequency and 3.8 GHz max turbo after installation?

Enter the system BIOS or use a hardware monitoring utility to confirm the processor reports 56 cores, 112 threads and reaches 3.8 GHz under load.

What comes in the box with the PK8071305074801 and what must I purchase separately?

The processor only is supplied; a compatible LGA 4677 cooler, DDR5 memory modules and a server motherboard must be bought separately.

Which memory speed should I select for the Xeon Platinum 8480+ given the 4800 MT/s 1DPC and 4400 MT/s 2DPC limits?

Choose DDR5 4800 MT/s modules if populating one DIMM per channel, or DDR5 4400 MT/s if filling two DIMMs per channel across the eight channels.
