White 140mm ARGB case fan with four-sided infinity mirror frame and aluminium nameplate

JONSBO

JONSBO ZA-120W 140mm ARGB case fan

SKU CH-0ST5-HAQCK MPN ZA-120W

A 140 mm white case fan with four-sided infinity mirror ARGB lighting, 700–2400 RPM, 20.95–65.26 CFM airflow and 20.3–36.6 dB(A) noise

  • Fan Size140mm
  • LEDARGB
  • TypeCase Fan
  • RPM700-2400 RPM
  • Air Flow20.95-65.26 CFM
  • Noise Level20.3-36.6 dB（A）

Model ZA-120W

Show 9 more configurations

Struck-through versions exist but are not stocked here.

  • Four-sided infinity mirror creates depth illusion
  • PWM control spans 700 to 2400 RPM for airflow up to 65.26 CFM
  • Noise stays between 20.3 and 36.6 dB(A) across the speed range
  • 3-pin ARGB plugs straight into motherboard for 16 million colour sync
  • 28 mm thick white frame fits standard 140 mm mounts

140mm ARGB Infinity Mirror Fan

The JONSBO ZA-120W is a 140mm white case fan built around a four-sided infinity mirror design that creates a layered visual effect. It targets builders who want addressable RGB lighting synchronized through a standard 3-pin 5V header without needing a separate controller. The 28mm thick frame houses an aluminium CD-pattern nameplate and uses a joint structure intended to simplify installation in compatible cases.

Airflow Range and Acoustic Limits

The fan spins between 700 and 2400 RPM, delivering 20.95 to 65.26 CFM of airflow with a static pressure range of 0.45 to 3.20 mmH2O. Noise output spans 20.3 to 36.6 dB(A) across the speed curve. At the lower end the unit runs quietly for idle or light workloads; at maximum speed it moves significantly more air but becomes audible, so it suits builds that can trade some noise for thermal headroom rather than strictly silent operation.

PWM and ARGB Connector Practicalities

A single 4-pin PWM header controls motor speed while a 3-pin 5V ARGB header handles lighting, both connecting directly to the motherboard. The integrated male and female connectors allow daisy-chaining multiple fans on one cable run, reducing cable count. Builders whose boards lack a 5V ARGB header cannot use the lighting sync feature, and systems without PWM support lose automatic speed control, relying instead on fixed voltage regulation.

Highlights

  • Four-sided infinity mirror creates depth illusion
  • PWM control spans 700 to 2400 RPM for airflow up to 65.26 CFM
  • Noise stays between 20.3 and 36.6 dB(A) across the speed range
  • 3-pin ARGB plugs straight into motherboard for 16 million colour sync
  • 28 mm thick white frame fits standard 140 mm mounts

Specifications

BrandJONSBO
SeriesZA SERIES
ModelZA-120W
Fan Size140mm
LEDARGB
TypeCase Fan
RPM700-2400 RPM
Air Flow20.95-65.26 CFM
Noise Level20.3-36.6 dB（A）
Power ConnectorPWM 4PIN ARGB 3PIN
ColorWhite
CompatibilityCase
Fan Counts1 Fan
Fan ControllerNo Controller
Fan Thickness28mm
Air Pressure0.45-3.20 mmH2O
FeaturesJONSBO ZA-120 T28MM ARGB Infinity Mirror Series Case Fan-
4-Sides Thousand- layer Mirror Illusion
Easy Installation of the Joint Structure
One Line Connection to Motherboard
Aluminum CD Pattern Nameplate
Addressable RGB sync- Insert 3PIN ARGB pins directly into the motherboard, synchronizing Over 16 million color effects
Quiet/Low Noise PWN fan
Specification:
ZA-120W(Regular)
COLOR: WHITE
Product Dimensions:4.72"L x 4.72"W x 1.1"H
Brand: JONSBO
Power Connector Type:4-Pin ARGB 3-Pin
Voltage: DC12 Volts LED 5V
Wattage:2.40 watts LED 3.55W
Cooling Method: Air
Compatible Devices:Desktop
Dimensions4.72"L x 4.72"W x 1.1"H

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 140 mm frame and 28 mm thickness fit the same mounting holes as my current 120 mm fans?

The fan uses a 140 mm square frame that is 28 mm thick, so it requires 140 mm mounting points; it will not align with 120 mm holes.

How can I confirm the ARGB lighting and PWM control are functioning after installation?

Connect the 3-pin ARGB header to a 5 V motherboard header and the 4-pin PWM header to a CPU or chassis fan header; lighting should sync in motherboard software and speed should vary between 700 and 2400 RPM under load.

Does the package include any ARGB or PWM cables, or do I need to buy them separately?

The fan has integrated male and female 4-pin PWM and 3-pin ARGB connectors for daisy-chaining; no separate cables or controller are included in the single-fan box.
