Green rectangular M.2 2280 SSD circuit board with black controller and NAND chips

KingSpec

KingSpec VP14000 1TB internal SSD

SKU CH-AT99-7X5G8

PCIe 5.0 M.2 2280 drive with sequential reads up to 14349 MBps and writes up to 8957 MBps for AI, gaming and heavy workloads

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D TLC
  • InterfacePCI-Express 5.0 x4

Capacity 1TB

  • Sequential read up to 14349 MB/s for near-instant load times
  • Sequential write up to 8957 MB/s keeps large-file workflows moving
  • Random read up to 1148000 IOPS for snappy multitasking
  • 600 TBW endurance rating protects heavy workloads
  • PCIe 5.0 x4 interface enables Gen5 platform performance

VP14000 1TB PCIe 5.0 NVMe drive

The KingSpec VP14000 is a 1TB internal SSD in M.2 2280 form factor using 3D TLC NAND. It connects through a PCIe 5.0 x4 interface with NVMe 2.0 protocol. The drive targets AI computing, gaming and heavy-duty workstation workloads where sequential throughput matters.

Sustained workload behaviour

Sequential reads reach 14349 MBps and writes 8957 MBps while random performance hits 1148000 IOPS read and 1038000 IOPS write. An eight-channel controller and optimised firmware maintain these rates during extended AI training, content creation or DirectStorage gaming sessions. The 600TB endurance rating supports long-term heavy use.

Thermals noise and power

A graphene layer provides heat dissipation without a heatsink, keeping temperatures stable under load. Idle power draws 1W and active consumption peaks at 4.4W. The drive operates silently with no moving parts and is rated for 1000000 hours MTBF.

Highlights

  • Sequential read up to 14349 MB/s for near-instant load times
  • Sequential write up to 8957 MB/s keeps large-file workflows moving
  • Random read up to 1148000 IOPS for snappy multitasking
  • 600 TBW endurance rating protects heavy workloads
  • PCIe 5.0 x4 interface enables Gen5 platform performance

Specifications

BrandKingSpec
SeriesVP Series
ModelVP14000
Part NumberVP14000-1TB
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D TLC
InterfacePCI-Express 5.0 x4
ProtocolNVMe 2.0
Max Sequential ReadUp to 14349 MBps
Max Sequential WriteUp to 8957 MBps
4KB Random ReadUp to 1148,000 IOPS
4KB Random WriteUp to 1038,000 IOPS
Terabytes Written (TBW)600TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)1W
Power Consumption (Active)4.4W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating Humidity5-95%
Height2.10mm
Width22mm
Depth80mm
Weight50g

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power does the VP14000 draw when it runs continuously at full load?

Active power consumption is 4.4W. The drive ships without a heatsink, so the motherboard M.2 slot or an aftermarket cooler must handle the heat generated at that power level.

What motherboard slot and protocol are required to install this 1TB drive?

An M.2 2280 slot wired for PCIe 5.0 x4 with NVMe 2.0 support is needed. The drive is backward compatible with PCIe 4.0 slots, though sequential speeds will be limited by the slower bus.

Will the VP14000 work in a PCIe 4.0 system without firmware changes?

Yes. The drive is backward compatible with PCIe 4.0 platforms. It will operate at PCIe 4.0 speeds automatically; no firmware update is required for the drive itself.
