Green M.2 2280 circuit board with black controller and NAND chips, no heatsink

KingSpec

KingSpec VP14000 2TB PCIe 5.0 x4 M.2 2280 internal SSD

SKU CH-D67X-0ZC1T

2 TB PCIe 5.0 x4 M.2 2280 internal SSD with sequential reads up to 14782 MB/s, writes up to 12914 MB/s and 1200 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D TLC
  • InterfacePCI-Express 5.0 x4

Capacity 2TB

  • PCIe 5.0 x4 interface delivers up to 14,782 MB/s sequential read for AI workloads
  • Up to 12,914 MB/s sequential write accelerates heavy-duty workstation tasks
  • 1,148,000 IOPS random read and 1,038,000 IOPS random write cut game load latency
  • 3D TLC NAND with 1,200 TBW and 1,000,000-hour MTBF ensures long-term reliability
  • Backward compatible with PCIe 4.0 platforms in M.2 2280 form factor for broad upgrades

Capacity and workload fit

The 2 TB drive targets consumer desktops, laptops and PS5 consoles that need space for large game libraries, AI datasets or creative projects. It uses 3D TLC NAND to balance speed and endurance for heavy daily use.

Interface limits and backward compatibility

The SSD runs on a PCIe 5.0 x4 link with NVMe 2.0 protocol and falls back to PCIe 4.0 platforms without firmware changes. Sequential throughput reaches 14,782 MB/s read and 12,914 MB/s write on a 5.0 host.

Endurance headroom and thermal behaviour

Rated at 1,200 TBW and 1,000,000 hours MTBF, the drive sustains long write-heavy workloads before wear becomes a concern. An ultra-thin graphene layer handles cooling so active power stays at 5.9 W without a bulky heatsink.

Highlights

  • PCIe 5.0 x4 interface delivers up to 14,782 MB/s sequential read for AI workloads
  • Up to 12,914 MB/s sequential write accelerates heavy-duty workstation tasks
  • 1,148,000 IOPS random read and 1,038,000 IOPS random write cut game load latency
  • 3D TLC NAND with 1,200 TBW and 1,000,000-hour MTBF ensures long-term reliability
  • Backward compatible with PCIe 4.0 platforms in M.2 2280 form factor for broad upgrades

Specifications

BrandKingSpec
SeriesVP Series
ModelVP14000
Part NumberVP14000-2TB
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D TLC
InterfacePCI-Express 5.0 x4
ProtocolNVMe 2.0
Max Sequential ReadUp to 14782 MBps
Max Sequential WriteUp to 12914 MBps
4KB Random ReadUp to 1148,000 IOPS
4KB Random WriteUp to 1038,000 IOPS
Terabytes Written (TBW)1200TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)1W
Power Consumption (Active)5.9W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating Humidity5-95%
Height2.10mm
Width22mm
Depth80mm
Weight50g

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How does the 2 TB capacity fit into the VP14000 range?

The VP14000 series scales up to 4 TB, so the 2 TB model sits at the midpoint, offering half the maximum capacity while keeping the same PCIe 5.0 x4 interface and 3D TLC NAND.

What does the 14 782 MB/s sequential read figure mean once the drive is installed?

That 14 782 MB/s is the peak sequential read speed under ideal conditions; real-world throughput will be lower and depends on workload, motherboard PCIe 5.0 lane allocation and thermal headroom.

What does the PCIe 5.0 x4 NVMe 2.0 interface cap in practice?

The x4 link limits theoretical bandwidth to the PCIe 5.0 ceiling, and the drive is backward compatible with PCIe 4.0 platforms where speeds will drop to that generation's maximum.
