M.2 2280 SSD with low-profile graphene aluminium heat spreader

Kingston Technology Corp.

Kingston Technology Corp. KC3000 SKC3000D/4096G internal SSD

SKU CH-J0V7-0K0S5 MPN SKC3000D/4096G

M.2 2280 internal SSD with 4096 GB capacity, PCIe 4.0 x4 NVMe interface, 7000 MB/s sequential speeds, 1,000,000 IOPS random performance, Phison E18 controller, 4 GB DRAM cache.

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity4096GB
  • Memory Components3D TLC
  • InterfacePCIe 4.0 x4 NVMe

Options 4TB

  • Up to 7000 MBps sequential read speeds for rapid data access
  • Up to 7000 MBps sequential write speeds for fast file transfers
  • 4GB DRAM cache enables sustained high throughput
  • 2PBW endurance rating supports heavy write workloads
  • 1,800,000 hours MTBF indicates long-term reliability

Capacity and Interface

The Kingston KC3000 SKC3000D/4096G is a 4096GB internal SSD built for consumer workloads that demand high throughput. It uses the M.2 2280 form factor and connects through a PCIe 4.0 x4 NVMe link driven by a Phison E18 controller with 4GB of DRAM cache. 3D TLC memory supports the rated endurance of 3.2PBW and an MTBF of 1,800,000 hours.

Thermals and Power

A low profile graphene aluminum heat spreader is fitted to the drive to manage temperatures during operation. The controller is specified to run between 0°C and +70°C. Power draw measures 5 mW at idle, 0.36W average active, 2.7W maximum read and 10.2W maximum write, keeping energy use low for a high performance NVMe device.

Sustained Load Behaviour

Under continuous heavy write workloads the heat spreader helps the controller maintain performance without rapid throttling. The drive is rated for 1,000,000 IOPS random read and write alongside 7000 MBps sequential read and write, figures that reflect steady state capability rather than short burst peaks. Vibration resistance is rated at 2.17G peak operating and 20G peak non operating.

Highlights

  • Up to 7000 MBps sequential read speeds for rapid data access
  • Up to 7000 MBps sequential write speeds for fast file transfers
  • 4GB DRAM cache enables sustained high throughput
  • 2PBW endurance rating supports heavy write workloads
  • 1,800,000 hours MTBF indicates long-term reliability

Specifications

BrandKingston
SeriesKC3000
ModelSKC3000D/4096G
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity4096GB
Memory Components3D TLC
InterfacePCIe 4.0 x4 NVMe
ProtocolNVMe
ControllerPhison E18
Cache4GB DRAM
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 7000 MBps
4KB Random ReadUp to 1,000,000 IOPS
4KB Random WriteUp to 1,000,000 IOPS
Terabytes Written (TBW)3.2PBW
MTBF1,800,000 hours
HeatSinkwith HeatSink
FeaturesPCIe 4.0 NVMe high-performance
Upgrade with full capacities up to 4096GB
Compact M.2 2280 form factor
Low profile graphene aluminum heat spreader
Power Consumption (Idle)5 mW
Power Consumption (Active)0.36W Avg / 2.7W (MAX) Read / 10.2W (MAX) Write
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Vibration ResistanceOperating: 2.17G Peak (7-800Hz)
Non-operating: 20G Peak (20-1000Hz)
Height3.50mm
Width22.00mm
Depth80.00mm
Weight9.70g
Shipping weight0.04 kg
Package size183 × 130 × 8 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the drive fit in a standard M.2 2280 slot with the heat spreader installed?

Yes. The low-profile graphene aluminum heat spreader keeps the drive at 3.50 mm height, which is within the standard M.2 2280 single-sided clearance.

Does the drive need a motherboard with PCIe 4.0 to reach the quoted speeds?

It will run on PCIe 3.0 slots, but the 7000 MBps sequential and 1,000,000 IOPS random figures require a PCIe 4.0 x4 NVMe connection.

Is the 4 GB DRAM cache used for mapping or user data?

The 4 GB DRAM cache stores the NVMe mapping tables, which sustains the 7000 MBps write speed and 3.2 PBW endurance rating.
