Silver square mini PC barebone, compact low-profile chassis

minisforum

minisforum DeskMini AI X1 Pro-470 AMD Ryzen AI 9 HX 470 barebone mini PC

SKU CH-WNYF-QY1Z9

Barebone mini PC with a 12-core Ryzen AI 9 HX 470, Radeon 890M graphics, Wi-Fi 7, Bluetooth 5.4, dual 2.5 Gbps LAN, four video outputs and DDR5-5600 slots for up to 128 GB

  • ColorSilver
  • AI FeaturesAvailable
  • CPU TypeAMD Ryzen AI 9 HX 470
  • CPU SocketFP8
  • CPU Cores12
  • Memory installedNo Memory

Option X1 Pro-470 · 0+0

Show 3 more configurations

Struck-through versions exist but are not stocked here.

  • 12-core Ryzen AI 9 HX 470 reaches 5.1 GHz boost for demanding workloads
  • AMD Radeon 890M integrated graphics drives four simultaneous displays via HDMI, DP and dual USB4
  • Dual 2.5 Gbps LAN ports plus Wi-Fi 7 and Bluetooth 5.4 deliver high-speed wired and wireless connectivity
  • Two DDR5-5600 SO-DIMM slots support up to 96 GB in dual-channel configuration
  • OCuLink port enables external PCIe 4.0 GPU expansion using one M.2 2280 slot

AI-ready barebone for custom builds

The minisforum DeskMini AI X1 Pro-470 is a barebone mini PC built around the AMD Ryzen AI 9 HX 470 processor with 12 cores and 24 threads. Integrated AMD Radeon 890M graphics handle display output. The chassis measures 7.68 by 7.68 by 1.67 inches and weighs 4.84 pounds. It targets builders who want to choose their own memory, storage and operating system.

Check memory slots and storage bays before ordering

The unit ships with no memory installed and no operating system. Two SO-DIMM slots accept DDR5 5600 modules up to 128 GB total in dual-channel mode. Two M.2 2280 PCIe 4.0 x4 slots and one PCIe 4.0 x1 slot provide internal storage expansion. An OCuLink port allows external GPU connection but uses one M.2 slot and is not hot-swappable.

Compact chassis with four video outputs

Four video ports — one HDMI, one DisplayPort and two USB4 — support up to four simultaneous displays. Dual 2.5 Gbps RJ45 ports, Wi-Fi 7 and Bluetooth 5.4 handle networking. The processor boost clock reaches 5.1 GHz. Front panel includes three USB ports and one audio jack. Thermal and acoustic behaviour will depend on the memory and storage components you install.

Highlights

  • 12-core Ryzen AI 9 HX 470 reaches 5.1 GHz boost for demanding workloads
  • AMD Radeon 890M integrated graphics drives four simultaneous displays via HDMI, DP and dual USB4
  • Dual 2.5 Gbps LAN ports plus Wi-Fi 7 and Bluetooth 5.4 deliver high-speed wired and wireless connectivity
  • Two DDR5-5600 SO-DIMM slots support up to 96 GB in dual-channel configuration
  • OCuLink port enables external PCIe 4.0 GPU expansion using one M.2 2280 slot

Specifications

BrandMINISFORUM
ModelDeskMini
ColorSilver
AI FeaturesAvailable
CPU TypeAMD Ryzen AI 9 HX 470
CPU SocketFP8
CPU Cores12
Memory installedNo Memory
Memory slot2
Memory Type SupportedDDR5 5600
Max Memory Supported128GB
Dual Channel Memory SupportedYes
Other2x PCIe4.0x4, 1x PCIe4.0x1
Integrated GraphicsAMD Radeon 890M
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 7
BluetoothBluetooth 5.4
Slim ODD2
Front USB3
Front Audio Ports1 jacks
HDMI1
DisplayPort1 x DisplayPort
RJ452
Dimensions7.68x7.68x1.67inch
Weight4.84lb

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the barebone include RAM, an SSD or an operating system, and what must I buy separately?

The unit ships with no memory, no storage and no OS. You must add two DDR5 5600 SO-DIMMs (up to 128 GB total) and one or two M.2 2280 PCIe 4.0 SSDs, then install your own operating system.

The spec sheet lists 128 GB maximum memory but also mentions 96 GB — which limit applies to this model?

The official maximum is 128 GB across the two DDR5 slots; the 96 GB figure appears in promotional material but the specification table confirms 128 GB.

What does the 5.1 GHz boost clock mean for everyday workloads once the system is assembled?

The Ryzen AI 9 HX 470 can reach 5.1 GHz boost across its 12 cores and 24 threads, giving strong single-thread responsiveness and multi-thread throughput for AI, rendering and compile tasks when paired with dual-channel DDR5 5600 memory.
